Ubiquiti U7 Pro XG 5800 PoE
£187.68 inc VAT
60 in stock
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- 6-stream WiFi 7 ceiling/wall AP with 10/5/2.5/1 GbE support
- 5800 Mbit/s max throughput across 2.4/5/6 GHz bands
- 300 user capacity with MU-MIMO and band steering
- PoE+ powered, 22 W max, metal/polycarbonate housing
- 140 m² coverage, 6 dBi internal antenna, wireless meshing
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
Ubiquiti U7 Pro XG | Ceiling-Mounted Wi-Fi 7 Access Point
The Ubiquiti U7 Pro XG 5800 Mbit/s Black Power over Ethernet (PoE) is a high-performance ceiling-mounted access point designed for demanding enterprise and large-scale environments. Delivering up to 5800 Mbps throughput across three bands, it supports up to 300 simultaneous users with robust management features.
Slim Specs Table
| Metric | Spec. |
|---|---|
| Wi-Fi Standard | Wi-Fi 7 (802.11be) |
| Throughput | 5800 Mbps |
| Frequency Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Spatial Streams | 6 |
| Ethernet Ports | 1 x 10/5/2.5/1 GbE |
Advanced Wi-Fi 7 Performance for High-Density Environments
Built on Wi-Fi 7 technology, the U7 Pro XG supports 6 spatial streams and multi-gigabit Ethernet, enabling seamless connectivity for up to 300 users. Its tri-band architecture ensures minimal interference and optimal device distribution, making it ideal for offices, schools, and hospitality venues.
Flexible Ceiling or Wall Mounting with Internal Antennas
Designed for discreet installation, the U7 Pro XG features internal antennas with 6 dBi gain and supports both ceiling and wall mounting. The compact 206 mm form factor and included mounting kit allow for clean, professional deployment in any environment.
Enterprise-Grade Management and Security
With support for VLANs, rate limiting, and PPSK security, this access point offers granular control over network access and performance. Fast roaming and band steering ensure uninterrupted connectivity for mobile users, while Wi-Fi scheduling allows for custom network availability.
Box contents
- Ubiquiti U7 Pro XG access point
- Mounting kit
- Power over Ethernet (PoE+) adapter
Check before you buy
- Confirm your network switch supports PoE+ for powering this device
- Verify ceiling or wall mounting is suitable for your installation
- Check that your network infrastructure supports 2.5 Gbps or higher Ethernet speeds
- Confirm you have UniFi Controller software for configuration and management
Frequently Asked Questions
Q: What Wi-Fi standard does the U7 Pro XG support?
A: It supports Wi-Fi 7 (802.11be) with 6 spatial streams across 2.4 GHz, 5 GHz, and 6 GHz bands.
Q: Does this access point support Power over Ethernet?
A: Yes, it supports PoE+ (802.3at) for both power and data connectivity.
Q: How many users can connect simultaneously?
A: The U7 Pro XG supports up to 300 simultaneous users.
Q: What is the maximum throughput speed?
A: Maximum combined throughput is 5800 Mbps across all bands.
Q: Can this be mounted on a wall?
A: Yes, it supports both ceiling and wall mounting using the included kit.
The Consultant’s verdict & warranty
The Ubiquiti U7 Pro XG is a premium Wi-Fi 7 access point suited for high-density environments requiring enterprise-grade performance and management. Its tri-band operation, 6 spatial streams, and PoE+ support make it a future-proof investment for growing networks. Covered by the standard Manufacturer Warranty.
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 1000,2500,5000,10000 Mbit/s |
| Maximum data transfer rate | 5800 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Reset button | Yes |
| Frequency band | 2.4, 5, 6 GHz |
| Number of users | 300 user(s) |
| VLAN support | Yes |
| Rate limiting | Yes |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Ethernet LAN data rates | 1000,2500,5000,10000 Mbit/s |
| Maximum data transfer rate | 5800 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Wireless LAN features | |
| Frequency band | 2.4, 5, 6 GHz |
| Network | |
| Number of users | 300 user(s) |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Management features | |
| VLAN support | Yes |
| Rate limiting | Yes |
| Access point management | Wi-Fi schedule |
| Features | |
| 6 GHz | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Frequency band | 2.4, 5, 6 GHz |
| Number of users | 300 user(s) |
| VLAN support | Yes |
| Rate limiting | Yes |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Ethernet LAN data rates | 1000,2500,5000,10000 Mbit/s |
| Maximum data transfer rate | 5800 Mbit/s |
| Fast roaming | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Maximum data transfer rate (2.4 GHz) | 688 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4300 Mbit/s |
| Fit AP mode features | Hotspot 2.0 |
| Maximum data transfer rate (6 GHz) | 5800 Mbit/s |
| Spatial streams | 6 |
| Coverage area | 140 m² |
| Wireless meshing | Yes |
| Maximum Tx power (2.4 GHz) | 23 dBmW |
| Maximum Tx power (5 GHz) | 26 dBmW |
| Maximum Tx power (6 GHz) | 24 dBmW |
| Security | |
| Security algorithms | PPSK |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power consumption (max) | 22 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
| Design | |
| Housing material | Metal, Polycarbonate (PC) |
| Placement | Ceiling, Wall |
| Product colour | Black |
| Reset button | Yes |
| LED indicators | Status |
| Antenna | |
| Antenna type | Internal |
| Antenna gain level (max) | 6 dBi |
| Technical details | |
| Reset button | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Indication | |
| LED indicators | Status |
| Software | |
| Fast roaming | Yes |
| Weight & dimensions | |
| Width | 206 mm |
| Depth | 32.5 mm |
| Weight | 750 g |
| Height | 206 mm |
| Packaging data | |
| Mounting kit | Yes |
| Packaging content | |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -30 - 40 °C |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Identifiers | |
| Additional EANs | 08101771621240 |
