GIGABYTE B850 Gaming X Motherboard
£179.95 inc VAT
21 in stock
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- AMD B850 chipset with Socket AM5 for Ryzen 9000 series CPUs
- 12+2+2 phase digital VRM for stable power delivery
- Up to 8200MHz DDR5 memory support with 4 DIMM slots
- Three M.2 slots with PCIe 5.0 and 4.0 configurations
- Wi-Fi 6E, 2.5Gb LAN, and Realtek ALC897 audio
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
GIGABYTE B850 GAMING X WIFI6E | AMD Ryzen 9000 Series Performance
The GIGABYTE B850 GAMING X WIFI6E motherboard delivers cutting-edge performance for AMD Ryzen 9000 Series CPUs with advanced power delivery and comprehensive connectivity. This ATX motherboard combines robust digital VRM design with next-generation DDR5 memory support up to 8200MHz (OC), making it ideal for gaming enthusiasts and content creators seeking uncompromising performance.
Slim Specs Table
| Metric | Spec |
|---|---|
| CPU Support | AMD Ryzen 7000/8000/9000 Series |
| Memory | DDR5, up to 8200MHz (OC) |
| M.2 Slots | 3 (1x PCIe 5.0, 2x PCIe 4.0) |
| Wi-Fi | WiFi 6E + 2.5Gb Ethernet |
Advanced Power Delivery for Ryzen 9000 CPUs
The 12+2+2 phase digital VRM design provides clean, stable power delivery for demanding AMD Ryzen 9000 Series processors. This robust power architecture ensures consistent performance during intensive workloads and gaming sessions, preventing thermal throttling and maintaining peak clock speeds when you need them most.
Next-Generation Storage Performance
With one PCIe 5.0 M.2 slot and two PCIe 4.0 M.2 slots, this motherboard supports the latest ultra-fast storage solutions. The PCIe 5.0 slot delivers theoretical speeds up to 128GB/s, while RAID 0, 1, and 10 configurations across seven total storage devices provide flexible data management options for both speed and redundancy.
Comprehensive Connectivity Suite
Modern connectivity needs are met with WiFi 6E, 2.5Gb Ethernet, and USB 3.2 Gen 2×2 ports. The WiFi 6E support provides access to the 6GHz band for reduced interference and faster wireless speeds, while multiple USB ports including Type-C ensure compatibility with the latest peripherals and devices.
Enhanced Cooling and System Monitoring
Comprehensive PC health monitoring tracks fan speeds, temperatures, voltages, and water cooling performance. With multiple fan headers including dedicated CPU and water pump connectors, plus four RGB LED headers for synchronized lighting control, you can maintain optimal thermal performance while customizing your system’s appearance.
Box contents
- GIGABYTE B850 GAMING X WIFI6E motherboard
- I/O shield
- User manual
- SATA cables
- M.2 screws
- Wi-Fi antennas
- CMOS battery
- Screws for installation
Check before you buy
- Confirm your CPU is compatible with Socket AM5 (Ryzen 7000/8000/9000 Series)
- Verify your case supports ATX motherboard dimensions (305mm x 244mm)
- Check that your power supply has the required 24-pin ATX and 8-pin EPS connectors
- Confirm your DDR5 memory is on the motherboard’s QVL list for optimal performance
Frequently Asked Questions
Q: What processors are compatible with this motherboard?
A: This motherboard supports AMD Ryzen 7000, 8000, and 9000 Series processors with the AM5 socket.
Q: How many M.2 slots does this motherboard have?
A: There are three M.2 slots: one PCIe 5.0 and two PCIe 4.0 slots for high-speed storage.
Q: What is the maximum memory speed supported?
A: The motherboard supports DDR5 memory up to 8200MHz when overclocked, with 256GB total capacity.
Q: Does this motherboard include WiFi?
A: Yes, it includes WiFi 6E with Bluetooth 5.3 for comprehensive wireless connectivity.
Q: What form factor is this motherboard?
A: This is a standard ATX motherboard measuring 305mm x 244mm.
The Consultant’s verdict & warranty
The GIGABYTE B850 GAMING X WIFI6E represents excellent value for users building systems around AMD’s latest Ryzen processors. Its combination of PCIe 5.0 storage, robust power delivery, and comprehensive connectivity makes it suitable for both gaming and professional applications. Covered by the standard Manufacturer Warranty.
| Internal I/O | |
|---|---|
| Number of M.2 (M) slots | 3 |
| Front panel connector | Yes |
| 12V power connector | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| TPM connector | Yes |
| Serial port headers | 1 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| RGB LED pin header | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Number of CPU fan connectors | 2 |
| Number of EPS power connectors (8-pin) | 1 |
| Number of water pump connectors | 2 |
| Number of RGB LED pin headers | 4 |
| Technical details | |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD B850 |
| Supported processor sockets | Socket AM5 |
| Serial port headers | 1 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Parallel processing technology support | Not supported |
| HDMI version | 2.1 |
| Motherboard form factor | ATX |
| Component for | PC |
| Warranty period | 3 year(s) |
| Audio | |
| Audio output channels | 7.1 channels |
| Performance | |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD B850 |
| RAID levels | 0, 1, 10 |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Processor | |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Supported processor sockets | Socket AM5 |
| Processor socket | Socket AM5 |
| Memory | |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 4400,4800,5200,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed (max) | 8200 MHz |
| ECC сompatibility | Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Storage controllers | |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 0, 1, 10 |
| Number of storage drives supported | 7 |
| RAID support | Yes |
| Graphics | |
| Parallel processing technology support | Not supported |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Rear panel I/O ports | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| DisplayPort version | 2.1 |
| USB 2.0 ports quantity | 3 |
| WiFi-AP antenna jack | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Realtek RTL8111H |
| Features | |
| Power source type | ATX |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD B850 |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Product colour | Brown |
| Expansion slots | |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| 1st M.2 largest key size | 25110 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 largest key size | 22110 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| BIOS | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| Clear CMOS button | Yes |
| System Management BIOS (SMBIOS) version | 2.7 |
| Desktop Management Interface (DMI) version | 2.7 |
| Power | |
| Power source type | ATX |
| Video | |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Packaging data | |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 2.38 kg |
| Software | |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Bundled software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Battery | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
| Country of origin | China |
| Weight & dimensions | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 2.38 kg |
| Weight | 2.1 kg |
| Width | 305 mm |
| Depth | 244 mm |
| Packaging content | |
| Bundled software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Batteries included | Yes |
| Screws included | Yes |
| Antenna included | Yes |
| Other features | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 2.38 kg |
| Weight | 2.1 kg |
