Asrock H610M-HDV/M.2+ Micro ATX Motherboard
£57.83 inc VAT
275 in stock
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- Intel H610 chipset for LGA 1700 processors
- Micro ATX form factor with 2 DDR5 DIMM slots
- 96 GB maximum memory capacity with dual-channel support
- 1 PCIe x16 Gen 4 and 1 PCIe x1 Gen 3 expansion slots
- 5 SATA III storage drives with Ultra M.2 32Gb/s interface
- 7.1 channel audio with Realtek ALC897 codec
- Gigabit Ethernet via Realtek RTL8111H controller
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
ASRock H610M-HDV/M.2+ D5 | Intel H610 Micro ATX Motherboard
The ASRock H610M-HDV/M.2+ D5 is a micro ATX motherboard built around the Intel H610 chipset, designed for Intel LGA 1700 processors. It offers a compact form factor with essential features for modern desktop builds, including DDR5 memory support, multiple display outputs, and enhanced connectivity options.
Key Specifications
| Metric | Spec |
|---|---|
| Processor Socket | LGA 1700 |
| Memory Support | DDR5, 2 x DIMM, up to 96 GB |
| Storage Interfaces | 5 x SATA III, 1 x M.2 (PCIe Gen3 x4) |
| Expansion Slots | 1 x PCIe x16 Gen 4, 1 x PCIe x1 Gen 3 |
| Graphics Outputs | 1 x HDMI, 1 x DisplayPort, 1 x VGA |
| Network | Gigabit Ethernet (Realtek RTL8111H) |
Power Delivery & Performance
Built with a 6+1+1 power phase design, this motherboard delivers stable and efficient power to Intel processors. The robust VRM components ensure smooth performance during demanding tasks, making it suitable for both everyday computing and light gaming workloads.
Storage & Connectivity
Featuring an Ultra M.2 slot with PCIe Gen3 x4 support, the H610M-HDV/M.2+ D5 enables transfer speeds up to 32Gb/s for ultra-fast NVMe SSDs. Alongside four SATA III ports, users can configure multiple storage devices for ample capacity and flexibility. USB 3.2 Gen1 Type-C on the rear I/O panel adds modern connectivity for peripherals.
Visual Output & Display Options
With three graphics outputs—HDMI, DisplayPort, and VGA—this motherboard supports triple monitor setups. The HDMI port is capable of 4K resolution at 60Hz, delivering crisp and fluid visuals for media consumption and productivity tasks.
RGB Lighting & Aesthetics
The integrated POLYCHROME RGB header allows connection to compatible LED devices such as strips, fans, and chassis lighting. Users can synchronise lighting effects across Polychrome RGB Sync-certified accessories to personalise their build’s appearance.
Box Contents
- ASRock H610M-HDV/M.2+ D5 motherboard
- I/O shield
- SATA cables (quantity not specified)
- User manual
- Driver/software installation guide
Check Before You Buy
- Confirm your Intel processor is LGA 1700 compatible.
- Verify DDR5 memory modules are supported.
- Check case dimensions for micro ATX compatibility.
- Ensure your power supply has a 24-pin ATX connector.
Frequently Asked Questions
Q: Does this motherboard support Wi-Fi?
A: No, this model does not include built-in Wi-Fi. A separate network card would be required.
Q: Can I use DDR4 memory with this board?
A: No, this motherboard only supports DDR5 memory modules.
Q: How many M.2 drives can I install?
A: There is one M.2 slot available for NVMe SSDs.
Q: Is the BIOS UEFI?
A: Yes, it features UEFI AMI BIOS with 128 Mbit flash storage.
The Consultant’s Verdict & Warranty
The ASRock H610M-HDV/M.2+ D5 offers a solid foundation for Intel-based micro ATX builds, combining DDR5 memory support, versatile display outputs, and reliable power delivery. It is well-suited for users seeking a compact yet capable platform for productivity, media, or light gaming. Covered by the standard Manufacturer Warranty.
| Technical details | |
|---|---|
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel H610 |
| Motherboard form factor | micro ATX |
| Component for | PC |
| Audio | |
| Audio output channels | 7.1 channels |
| Performance | |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel H610 |
| Audio output channels | 7.1 channels |
| Motherboard form factor | micro ATX |
| Component for | PC |
| Processor | |
| Processor manufacturer | Intel |
| Maximum number of SMP processors | 1 |
| Processor socket | LGA 1700 |
| Memory | |
| Number of memory slots | 2 |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Maximum internal memory | 96 GB |
| Unbuffered memory | No |
| ECC сompatibility | Non-ECC |
| Storage controllers | |
| Supported storage drive interfaces | SATA III |
| Number of storage drives supported | 5 |
| Internal I/O | |
| Supported storage drive interfaces | SATA III |
| USB 2.0 connectors | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| TPM connector | Yes |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Rear panel I/O ports | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DisplayPort version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Realtek RTL8111H |
| Ethernet interface type | Gigabit Ethernet |
| Features | |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel H610 |
| Audio output channels | 7.1 channels |
| Motherboard form factor | micro ATX |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Expansion slots | |
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| BIOS | |
| BIOS type | UEFI AMI |
| BIOS memory size | 128 Mbit |
| Software | |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Weight & dimensions | |
| Width | 220 mm |
| Depth | 193 mm |
