GIGABYTE B760 GAMING X Motherboard – Intel 14th Gen, DDR5, PCIe 4.0 M.2, 2.5GbE LAN
£121.43 inc VAT
Out of stock
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- Intel B760 Express chipset with LGA 1700 socket for 14th Gen CPUs
- Triple M.2 slots with PCIe 4.0 support for ultra-fast storage
- DDR5 memory support up to 7600 MHz for extreme performance
- 2.5GbE LAN and 7.1 channel audio for immersive connectivity
- ATX form factor with comprehensive cooling and RGB headers
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
GIGABYTE B760 GAMING X | Intel 14th Gen Ready Motherboard
The GIGABYTE B760 GAMING X Motherboard is engineered for high-performance PC builds, supporting Intel Core 14th Gen CPUs with robust power delivery and advanced connectivity options. This ATX motherboard delivers exceptional stability and speed for gamers, content creators, and professionals seeking reliable performance.
Key Specifications
| Metric | Spec |
|---|---|
| CPU Support | Intel Core 14th Gen, LGA 1700 |
| Memory Support | DDR5, up to 7600MHz (OC) |
| PCIe Slots | 1x PCIe 4.0 x16 |
| M.2 Slots | 3x PCIe 4.0 M.2 |
| LAN | 2.5GbE |
| USB | USB 3.2 Gen 2 |
Unmatched Performance for Intel 14th Gen Processors
Built with an 8+1+1 phase digital VRM design, this motherboard delivers clean, stable power to Intel’s latest 14th generation processors. The enhanced power delivery system ensures consistent performance during intensive workloads, gaming sessions, or content creation tasks. The LGA 1700 socket provides future-proof compatibility with Intel’s evolving processor lineup.
Advanced DDR5 Memory Support
Experience blazing-fast memory speeds with support for DDR5 memory up to 7600MHz when overclocked. The dual-channel architecture maximizes bandwidth for demanding applications, while the four DIMM slots support up to 256GB of total memory. Whether you’re running virtual machines, editing 4K video, or gaming at high settings, this motherboard’s memory capabilities won’t hold you back.
Blazing-Fast Storage Solutions
With three PCIe 4.0 M.2 slots, you can install multiple high-speed NVMe SSDs for rapid data access and reduced loading times. The motherboard supports both M.2 and SATA III storage interfaces, providing flexibility for your storage configuration. RAID 0, 1, 5, and 10 support allows you to optimize storage performance or create redundant backups for critical data.
Comprehensive Connectivity Options
Stay connected with 2.5GbE LAN for lag-free online gaming and fast file transfers. The motherboard features multiple USB ports including USB 3.2 Gen 2 for high-speed peripherals, plus HDMI 2.0 and DisplayPort 1.2 outputs for multi-monitor setups. With 7.1 channel audio support, you’ll enjoy immersive sound for gaming, movies, and music production.
Box contents
- GIGABYTE B760 GAMING X Motherboard
- I/O shield
- SATA cables
- User manual
- Driver/software CD
- Warranty card
Check before you buy
- Confirm your CPU is compatible with LGA 1700 socket
- Verify your case supports ATX motherboard form factor
- Check that your power supply has required 24-pin ATX and 8-pin EPS connectors
- Ensure your DDR5 memory is on the motherboard’s qualified vendor list
Frequently Asked Questions
Q: Does this motherboard support WiFi?
A: No, this motherboard does not include built-in WiFi. You would need to use a WiFi adapter or Ethernet connection.
Q: What is the maximum memory capacity supported?
A: The motherboard supports up to 256GB of DDR5 memory across four DIMM slots.
Q: Can I use this with older Intel processors?
A: This motherboard is specifically designed for Intel 12th and 13th generation processors on the LGA 1700 socket.
Q: How many graphics cards can I install?
A: The motherboard has one PCIe 4.0 x16 slot for a single graphics card installation.
Q: Is RGB lighting supported?
A: Yes, the motherboard includes RGB LED headers for customizable lighting effects.
The Consultant’s verdict & warranty
The GIGABYTE B760 GAMING X Motherboard offers exceptional value for users building systems around Intel’s 14th Gen processors. With robust power delivery, advanced DDR5 support, and comprehensive connectivity options, it delivers reliable performance for gaming, content creation, and professional applications. Covered by the standard Manufacturer Warranty.
| Internal I/O | |
|---|---|
| Number of M.2 (M) slots | 3 |
| Number of SATA Express connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Front panel connector | Yes |
| 12V power connector | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| TPM connector | Yes |
| Serial port headers | 1 |
| S/PDIF out connector | Yes |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| RGB LED pin header | Yes |
| Technical details | |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B760 Express |
| Supported processor sockets | LGA 1700 |
| Serial port headers | 1 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Parallel processing technology support | Not supported |
| HDMI version | 2.0 |
| Motherboard form factor | ATX |
| Component for | PC |
| Warranty period | 3 year(s) |
| Audio | |
| Audio output channels | 7.1 channels |
| Performance | |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B760 Express |
| RAID levels | 0, 1, 5, 10 |
| Supported processor sockets | LGA 1700 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Processor | |
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Supported processor sockets | LGA 1700 |
| Processor socket | LGA 1700 |
| Memory | |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 4000,4800,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed (max) | 7600 MHz |
| ECC сompatibility | ECC & Non-ECC |
| Storage controllers | |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 0, 1, 5, 10 |
| Number of storage drives supported | 7 |
| RAID support | Yes |
| Graphics | |
| Parallel processing technology support | Not supported |
| Maximum resolution | 4096 x 2304 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Rear panel I/O ports | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| DisplayPort version | 1.2 |
| USB connector type | USB Type-A, USB Type-C |
| USB 2.0 ports quantity | 5 |
| Microphone in | Yes |
| Headphone outputs | 6 |
| HDMI version | 2.0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Features | |
| Power source type | ATX |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B760 Express |
| Supported processor sockets | LGA 1700 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Product colour | Brown |
| Expansion slots | |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| 1st M.2 largest key size | 22110 |
| 1st M.2 highest PCI Express generation | 4.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 largest key size | 22110 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| BIOS | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Desktop Management Interface (DMI) version | 2.7 |
| Power | |
| Power source type | ATX |
| Video | |
| Maximum resolution | 4096 x 2304 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Packaging data | |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 1.86 kg |
| Software | |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Bundled software | Norton Internet Security |
| Battery | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
| Country of origin | China |
| Weight & dimensions | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 1.86 kg |
| Width | 305 mm |
| Depth | 244 mm |
| Packaging content | |
| Cables included | SATA |
| Bundled software | Norton Internet Security |
| Batteries included | Yes |
| Other features | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 1.86 kg |
