GIGABYTE X870 AORUS STEALTH Motherboard – AMD Ryzen 9000, DDR5 8200MHz, PCIe 5.0/4.0, Wi-Fi 7, 5 GbE, USB 4
£309.32 inc VAT
2 in stock
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- Supports AMD Ryzen 9000 CPUs with Socket AM5
- 4 M.2 slots with PCIe 5.0 and 4.0 support
- Dual-channel DDR5 memory up to 8200MHz
- Wi-Fi 7 and 5 GbE LAN for fast connectivity
- ATX form factor with passive cooling
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
GIGABYTE X870 AORUS STEALTH | AMD AM5 Powerhouse
The GIGABYTE X870 AORUS STEALTH Motherboard – Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8200Hz DDR5 (OC), 2xPCIe 5.0 + 2xPCIe 4.0, Wi-Fi 7, 5 GbE LAN, USB 4 is built for enthusiasts demanding extreme performance. Engineered for AMD Ryzen 9000 Series processors, it delivers cutting-edge connectivity, robust power delivery, and next-gen storage options.
| Metric | Spec. |
|---|---|
| Socket | AMD AM5 |
| Memory Support | DDR5 up to 8200MHz (OC) |
| PCIe Slots | 2x PCIe 5.0, 2x PCIe 4.0 |
| M.2 Slots | 4 (2x PCIe 5.0, 2x PCIe 4.0) |
| Wi-Fi | Wi-Fi 7 + Bluetooth 5.4 |
| LAN | 5 GbE + 2.5 GbE |
Extreme Performance with 16+2+2 Digital VRM
The 16+2+2 phase digital VRM design ensures rock-solid power delivery to AMD Ryzen 9000 CPUs under heavy loads. This architecture minimises voltage drops during intense gaming or content creation, keeping your system stable and responsive. Combined with advanced thermal management, it maintains optimal performance even during extended sessions.
Next-Gen Connectivity & Storage
With two PCIe 5.0 slots and four M.2 slots (two supporting PCIe 5.0), this motherboard future-proofs your build. Enjoy blistering NVMe SSD speeds for ultra-fast boot times and game loading. The inclusion of Wi-Fi 7 and dual LAN ports (5 GbE + 2.5 GbE) ensures lag-free online experiences and rapid file transfers.
Enhanced Audio & Cooling Features
The ALC1220 audio codec delivers immersive 7.1-channel sound quality, perfect for gaming and media consumption. Comprehensive cooling support includes six chassis fan headers, three water pump headers, and temperature sensors, allowing precise thermal control. The passive cooling design keeps noise levels minimal while maintaining efficiency.
Box contents
- GIGABYTE X870 AORUS STEALTH Motherboard
- I/O shield
- SATA cables (quantity not specified)
- User manual
- Warranty card
- Motherboard screws
- Wi-Fi antennas
Check before you buy
- Confirm your AMD Ryzen 9000 Series CPU is compatible with AM5 socket.
- Verify your case supports ATX form factor (305 x 244 mm).
- Check if your PSU provides sufficient PCIe power connectors.
- Ensure your cooling solution fits the motherboard layout.
Frequently Asked Questions
Q: Does this motherboard support DDR4 memory?
A: No, it only supports DDR5-SDRAM memory modules.
Q: How many graphics cards can I install?
A: You can install up to two graphics cards using the PCIe 5.0 x16 slots.
Q: Is Wi-Fi 7 backwards compatible?
A: Yes, Wi-Fi 7 is backwards compatible with previous Wi-Fi standards.
Q: What is the maximum supported RAM capacity?
A: The motherboard supports up to 256 GB of DDR5 memory across four DIMM slots.
Q: Does it include RGB lighting?
A: Yes, it features RGB LED headers for customisable lighting setups.
The Consultant’s verdict & warranty
The GIGABYTE X870 AORUS STEALTH is ideal for PC builders seeking top-tier performance with AMD Ryzen 9000 CPUs. Its robust VRM, extensive connectivity, and advanced cooling make it perfect for gaming, content creation, and professional workloads. Covered by the standard Manufacturer Warranty.
| Internal I/O | |
|---|---|
| Number of M.2 (M) slots | 4 |
| Front panel connector | Yes |
| 12V power connector | Yes |
| Supported storage drive interfaces | M.2, PCI Express 4.0, PCI Express 5.0, SATA III |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| TPM connector | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Number of SATA III connectors | 2 |
| Number of chassis fan connectors | 6 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| RGB LED pin header | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Number of CPU fan connectors | 2 |
| Number of EPS power connectors (8-pin) | 1 |
| Number of water pump connectors | 3 |
| Number of temperature sensor headers | 2 |
| Number of noise detection headers | 1 |
| Number of RGB LED pin headers | 4 |
| Technical details | |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD X870 |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Parallel processing technology support | Not supported |
| On-board graphics card | No |
| HDMI version | 2.1 |
| Cooling type | Passive |
| Motherboard form factor | ATX |
| Component for | PC |
| Warranty period | 3 year(s) |
| Audio | |
| Audio output channels | 7.1 channels |
| Performance | |
| Number of HDDs supported | 2 |
| Supported storage drive types | HDD & SSD |
| Windows operating systems supported | Windows 11 x64 |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD X870 |
| RAID levels | 0, 1, 5, 10 |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Cooling type | Passive |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Processor | |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Supported processor sockets | Socket AM5 |
| Processor socket | Socket AM5 |
| Memory | |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed (max) | 8200 MHz |
| ECC сompatibility | Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Storage controllers | |
| Number of HDDs supported | 2 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, PCI Express 4.0, PCI Express 5.0, SATA III |
| RAID levels | 0, 1, 5, 10 |
| Number of storage drives supported | 6 |
| RAID support | Yes |
| Graphics | |
| Parallel processing technology support | Not supported |
| On-board graphics card | No |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| HDCP version | 2.3 |
| Rear panel I/O ports | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| DisplayPort version | 1.4 |
| USB 2.0 ports quantity | 4 |
| WiFi-AP antenna jack | 2 |
| S/PDIF out port | Yes |
| Headphone outputs | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Digital audio optical out | 1 |
| USB4 Gen 3x2 ports quantity | 2 |
| Line-in | Yes |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| LAN controller | Realtek RTL8126 |
| Ethernet interface type | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN controller model | Qualcomm QCNCM865 |
| Features | |
| Power source type | ATX |
| Windows operating systems supported | Windows 11 x64 |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD X870 |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Cooling type | Passive |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Audio chip | Realtek ALC1220 |
| Product colour | Black |
| Expansion slots | |
| Number of M.2 (M) slots | 4 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| 1st M.2 largest key size | 25110 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 5.0 |
| 3rd M.2 largest key size | 22110 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| 4th M.2 largest key size | 22110 |
| 4th M.2 highest PCI Express generation | 4.0 |
| BIOS | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery capacity | 220 mAh |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 512 Mbit |
| ACPI version | 5.0 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Desktop Management Interface (DMI) version | 2.7 |
| Power | |
| Power source type | ATX |
| Video | |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Packaging data | |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 5.1 kg |
| Software | |
| Windows operating systems supported | Windows 11 x64 |
| Bundled software | Norton® Internet Security (OEM version) |
| Battery | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery capacity | 220 mAh |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
| Country of origin | China |
| Weight & dimensions | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 5.1 kg |
| Weight | 4.42 kg |
| Width | 305 mm |
| Depth | 244 mm |
| Packaging content | |
| Bundled software | Norton® Internet Security (OEM version) |
| Batteries included | Yes |
| Screws included | Yes |
| Antenna included | Yes |
| Other features | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 5.1 kg |
| Weight | 4.42 kg |
| Identifiers | |
| Additional EANs | 0889523056073 |
