StarTech.com 20m LC to LC OM5 Duplex Fiber Cable, LSZH
£55.31 inc VAT
Out of stock
Out of stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- 20m OM5 duplex multimode fibre cable with LC to LC connectors
- LSZH low-smoke zero-halogen jacket for enhanced safety
- Supports 100 Gbit/s data transfer via SWDM over 850–953 nm wavelengths
- Backward compatible with OM4 and OM3 10G networks
- 6 cm bending radius with RoHS and CE compliance
- Operating temperature range of -20°C to 60°C
- 50/125 µm core/cladding with 30 dB return loss
Payment Methods:
You may also like
StarTech.com 20m LC to LC OM5 Multimode Fibre Optic Cable | 100G LSZH
The StarTech.com 20m (65.6ft) LC to LC (UPC) OM5 Multimode Fiber Optic Cable, 50/125µm Duplex LOMMF Zipcord, VCSEL, 40G/100G, LSZH Fiber Jumper Cord supports SWDM applications over OM5 networks. It is designed for IT professionals in UK data centres requiring reliable 40G or 100G connectivity. Because it uses LSZH jacket material, this cable is suitable for installations with strict fire safety regulations.
Slim Specifications
| Metric | Specification |
|---|---|
| Cable Length | 20 m |
| Fibre Type | OM5 Multimode |
| Connectors | LC to LC (UPC) |
| Cable Diameter | 2.9 mm |
| Operating Temp | -20 to 60 °C |
| Data Rate | Up to 100 Gbit/s |
High-Speed SWDM Support
This OM5 cable facilitates Shortwave Wavelength Division Multiplexing (SWDM). It operates across 850–953 nm wavelengths for VCSEL sources. This capability allows you to transmit 40G and 100G data over fewer strands. Consequently, it optimises infrastructure utilisation in high-density environments.
Precision Alignment for Low Loss
Precision-manufactured ceramic ferrules ensure correct fibre alignment. The LC UPC polished ends minimise insertion loss and improve return loss. Because of this engineering, the cable maintains signal integrity in demanding network applications. It connects directly to LC ports on modern switches and transceivers.
Backward Compatibility
This 50/125µm duplex cord is backward compatible with OM4 and OM3 networks. You can deploy it in legacy 10G environments without issue. However, you must verify that your transceivers support OM5 specifications for optimal performance. It does not support single-mode applications.
Enhanced Safety with LSZH
The cable features a Low Smoke Zero Halogen (LSZH) jacket. In the event of extreme heat or fire, it emits minimal smoke and no toxic halogen compounds. This makes it a preferred choice for UK installations in confined spaces, such as trains or aircraft, and areas requiring compliance with specific building codes.
Robust Physical Design
With a bending radius of 6 cm, this cable resists tight turns that could damage the fibre. It operates reliably in temperatures ranging from -20°C to 60°C. The green duplex zipcord design aids in cable management and identification within complex racks.
Box contents
- 1 x StarTech.com 20m LC to LC OM5 Multimode Fibre Optic Cable
Check before you buy
- Confirm your network switches support OM5 multimode fibre specifications.
- Verify that your SFP or QSFP transceivers use LC UPC connectors.
- Ensure your installation environment adheres to LSZH fire safety requirements.
- Check that the 20m length accommodates your rack layout without excessive slack.
Frequently Asked Questions
Is this cable compatible with OM4 networks?
What is the maximum data transfer rate?
Does the LSZH jacket affect cable flexibility?
What is the bending radius of this cable?
Are the connectors gender-specific?
Our recommendation
This cable is ideal for UK data centre managers upgrading to 100G SWDM infrastructure while maintaining OM4 compatibility. It offers a safe, LSZH-rated solution for high-density environments. Covered by the applicable manufacturer warranty.
| Jacket material | Low smoke zero halogen (LSZH) |
|---|---|
| Fiber mode structure | Multi-mode |
| Connector 1 | LC |
| Connector 2 | LC |
| Cable type | LOMM |
| Cable length | 20 m |
| Full duplex | Yes |
| Core diameter | 50 µm |
| Cladding diameter | 125 µm |
| Sustainability compliance | Yes |
| Compliance certificates | RoHS, CE |
| Bending radius | 6 cm |
| Fibre optic type | OM5 |
| Return loss | 30 dB |
| Operating temperature T-T | -20 – 60 °C |
| Storage temperature T-T | -20 – 60 °C |
| Data transfer rate | 100 Gbit/s |
| Wavelengths supported | 953,1300,850 nm |
| Product colour | Green |
| Connector 2 gender | Male |
| Connector 1 gender | Male |
| Package width | 330 mm |
| Package depth | 255 mm |
| Package height | 41 mm |
| Cable diameter | 2.9 mm |
| Package weight | 156 g |
| Quantity per pack | 1 pc(s) |
| Master outer case width | 410 mm |
| Master outer case length | 410 mm |
| Master outer case height | 450 mm |
| Products per master outer case | 40 pc(s) |
| Distributor SKUs | CI91377, 9029791, LCLCL20MOM5FBR |
