Intel Core i9-14900K CPU LGA1700 Tray
£532.62 inc VAT
In stock
In stock
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- Intel Core i9-14900K processor with 24 cores (8 Performance + 16 Efficient) and 32 threads
- Boost frequency up to 6 GHz via Intel Thermal Velocity Boost and Turbo Boost Max 3.0
- 36 MB Smart Cache with L2 cache of 32,768 KB
- Supports up to 192 GB DDR4-SDRAM and DDR5-SDRAM with dual-channel memory
- LGA 1700 socket with Tray package type for desktop systems
- Integrated Intel UHD Graphics 770 supporting 4 displays and resolutions up to 7680 x 4320 pixels
Payment Methods:
You may also like
Intel Core i9-14900K | 24-Core Desktop Processor (Tray)
This Intel Core i9-14900K processor 36 MB Smart Cache Tray targets high-end desktop builders in the UK. It offers a max boost frequency of 6 GHz for demanding workloads. The processor uses a hybrid architecture with 24 cores for efficiency.
Intel Core i9-14900K processor 36 MB Smart Cache Tray
Key Specifications
| Metric | Spec. |
|---|---|
| Processor Cores | 24 (8 P-cores, 16 E-cores) |
| Max Boost Frequency | 6 GHz |
| Processor Cache | 36 MB Smart Cache |
| Socket | LGA 1700 |
| Max Memory Support | 192 GB (DDR4/DDR5) |
| Base Power | 125 W |
Hybrid Core Architecture
This processor uses a hybrid design. It combines 8 performance cores with 16 efficient cores. This allows the CPU to handle heavy tasks and background processes effectively. You get high throughput for professional workloads.
Extreme Boost Frequencies
The chip supports a max turbo frequency of 6 GHz. Performance cores can boost to 5.6 GHz. Efficient cores reach 4.4 GHz. These speeds aid fast rendering and compilation times. Intel Thermal Velocity Boost and Intel Turbo Boost Max Technology 3.0 drive this performance.
Memory and Cache Performance
It features 36 MB of Intel Smart Cache. The processor supports up to 192 GB of memory. It works with both DDR4 and DDR5 modules. Dual-channel memory architecture provides 89.6 GB/s bandwidth. This reduces bottlenecks in data-heavy tasks.
Integrated Graphics Capabilities
The CPU includes Intel UHD Graphics 770. It supports up to four displays via HDMI 2.1 and DisplayPort 1.4a. Maximum resolution reaches 8K (7680 x 4320) on DisplayPort. This is useful for multi-monitor setups without a discrete GPU.
Platform and Expansion
The processor fits the LGA 1700 socket. It supports PCI Express 5.0 and 4.0 lanes. Configurations include 1×16+1×4 or 2×8+1×4. This ensures high bandwidth for next-gen graphics and storage. Note that this is a tray processor. A separate cooling solution is required.
Box contents
- Intel Core i9-14900K Processor (Tray)
- Processor documentation
Check before you buy
- Confirm you have an LGA 1700 socket motherboard.
- Verify your cooling solution supports high TDP (up to 253 W).
- Check motherboard BIOS supports 14th Gen Intel Core processors.
- Confirm memory type (DDR4 or DDR5) matches your motherboard specifications.
Frequently Asked Questions
Q: Does this processor include a cooler?
A: No, this is a tray processor. You must purchase a compatible LGA 1700 cooler separately.
Q: Is this processor compatible with DDR4?
A: Yes, it supports both DDR4 and DDR5 memory. Compatibility depends on your motherboard choice.
Q: What is the difference between a tray and a box processor?
A: A tray processor ships without retail packaging or a cooler. It is typically for system builders.
Q: Does this CPU support overclocking?
A: Yes, the “K” series is unlocked. It requires a compatible Z-series motherboard.
Q: What is the max memory capacity?
A: The processor supports up to 192 GB of system memory across two channels.
Q: Does it have integrated graphics?
A: Yes, it features Intel UHD Graphics 770 with support for 8K displays.
The Consultant’s verdict & warranty
This Intel Core i9-14900K is suited for UK enthusiasts and professionals needing top-tier desktop performance. It excels in gaming, content creation, and heavy multitasking. The hybrid architecture balances speed and efficiency well. Covered by the standard Manufacturer Warranty.
| Processor | |
|---|---|
| Processor generation | Intel® Core™ i9 (14th gen) |
| Processor manufacturer | Intel |
| Processor codename | Raptor Lake |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor cache | 36 MB |
| Processor ARK ID | 236773 |
| Processor model | i9-14900K |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 6 GHz |
| Stepping | B0 |
| Processor family | Intel® Core™ i9 |
| Processor cores | 24 |
| Processor socket | LGA 1700 |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Performance cores | 8 |
| Efficient cores | 16 |
| Performance-core boost frequency | 5.6 GHz |
| Performance-core base frequency | 3.2 GHz |
| Efficient-core boost frequency | 4.4 GHz |
| Efficient-core base frequency | 2.4 GHz |
| Processor base power | 125 W |
| Maximum turbo power | 253 W |
| Maximum number of DMI lanes | 8 |
| Memory | |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 89.6 GB/s |
| ECC | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| Number of execution units | 32 |
| On-board graphics card ID | 0xA780 |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card | Yes |
| On-board graphics card dynamic frequency (max) | 1650 MHz |
| On-board graphics card base frequency | 300 MHz |
| Discrete graphics card model | Not available |
| Multi-Format Codec Engines | 2 |
| Technical details | |
| Thermal solution specification | PCG 2020A |
| Intel® Secure Key | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| PCI Express slots version | 4.0, 5.0 |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Scalability | 1S |
| L2 cache | 32768 KB |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Status | Launched |
| Market segment | Desktop |
| Launch date | Q4'23 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor cache type | Smart Cache |
| OpenCL version | 3.0 |
| Features | |
| On-board graphics card ID | 0xA780 |
| Maximum number of PCI Express lanes | 20 |
| Processor package size | 45 x 37.5 mm |
| Processor ARK ID | 236773 |
| Thermal solution specification | PCG 2020A |
| Thermal Monitoring Technologies | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 4.0, 5.0 |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Scalability | 1S |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Market segment | Desktop |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Use conditions | Workstation, PC/Client/Tablet |
| Direct Media Interface (DMI) Revision | 4.0 |
| Processor special features | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.8 GHz |
| Intel® Thermal Velocity Boost Frequency | 6 GHz |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Thread Director | Yes |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Operational conditions | |
| Tjunction | 100 °C |
| Packaging data | |
| Package type | Tray |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
| Processor package size | 45 x 37.5 mm |
| Other features | |
| Maximum internal memory | 192 GB |
| L2 cache | 32768 KB |
| CPU configuration (max) | 1 |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Identifiers | |
| Distributor SKUs | 10397096, 493368, CI65648, STD10211975, 8670387, 124227, 99CFFC |
| Additional EANs | 5056489771257 |
