StarTech.com PEXUSB312A3 2-Port USB 3.2 Gen 2 (10Gbps) PCIe Expansion Card – Black
£34.81
Out of stock
Out of stock
-
DPD tracked delivery
-
Buy now, pay later with Klarna
-
Pay in 3 instalments with PayPal
About This Item
- Two 10Gbps USB 3.2 Gen 2 Type-A ports
- PCIe 3.0 x4 host interface
- Supports full-height and low-profile installations
- Compatible with Windows, macOS, and Linux
- Includes SATA 15-pin power connector
- Maximum data transfer rate of 10 Gbit/s
You may also like
StarTech.com PEX4S03LP 4-Port PCIe RS232 Serial Adapter Card 921.6Kbit/s – Windows/Linux
In stock
StarTech.com 1U Brush Strip Cable Management Panel, Steel
In stock
StarTech.com 4-Port USB 3.2 Gen 1 PCIe Card 5Gbps with 4x USB-A Ports Black
In stock
ASUS IPMI Expansion Card Adapter
In stock
StarTech.com 2in Offset Horizontal Cable Lacing Bars – 10 Pack
In stock
StarTech.com 7-Port PCIe USB 3.0 Card – 5Gbps – Standard & Low-Profile Design
In stock
StarTech.com Vertical Cable Organiser – 0U – 6 ft
In stock
ASUS Hyper M.2 x16 Gen 4 PCIe 4.0 Adapter Card, 4x NVMe M.2 SSD Support, Active Cooling, Silver
In stock
StarTech.com 2-Port PCIe RS232 Serial Adapter Card with 16950 UART, 921.6Kbps, Asix AX99100, Green
In stock
StarTech.com PEXUSB312A3 – Boost Your PC’s Connectivity
We are pleased to offer the StarTech.com PEXUSB312A3 2-Port USB 3.2 Gen 2 (10Gbps) PCIe Expansion Card – Black. This card is ideal for users needing to upgrade their desktop with high-speed USB-A ports. It provides a simple, effective way to enhance your system’s data transfer capabilities.
Core Connectivity Details
| Metric | Spec. |
|---|---|
| USB Ports | 2x USB 3.2 Gen 2 Type-A |
| Data Transfer Rate | 10 Gbps per port |
| Host Interface | PCIe 3.0 x4 |
| Form Factor | Full-height / Low-profile |
| Internal Power | 1x SATA 15-pin |
Ultra-Fast Data Transfers
Experience rapid data movement with two USB 3.2 Gen 2 ports. Each port offers speeds up to 10 Gbps. This is perfect for external hard drives and SSDs. You will notice a significant improvement when transferring large files.
Broad System Integration
This expansion card supports various operating systems. It works with Windows, Linux, and macOS. Installation is straightforward, with automatic driver setup for Windows 8 and newer. This ensures wide compatibility across different setups.
Flexible Installation Options
We include both full-profile and low-profile brackets. This means the card fits into most desktop cases. You can install it in either a standard or small form factor PCIe 3.0 x4 slot. It is also backward compatible with PCIe 2.0.
Enhanced Performance with UASP
The card incorporates UASP (USB Attached SCSI Protocol). This technology boosts performance with supported storage devices. It optimises data transfers, making your external drives even faster. This is particularly beneficial for demanding tasks.
What You Receive
- PCIe USB 3.2 Gen 2 Expansion Card
- Low-profile bracket
- Quick installation guide
Before You Order
- Confirm your computer has an available PCIe x4 slot or higher.
- Confirm your power supply has a spare SATA 15-pin power connector.
- Confirm your operating system is supported for optimal performance.
Frequently Asked Questions
Q: What is the maximum data transfer rate?
A: Each USB 3.2 Gen 2 port supports up to 10 Gbps for fast data transfers.
Q: Does this card require a separate power connection?
A: Yes, it requires a single internal SATA 15-pin power connector.
Q: Is this card compatible with older USB devices?
A: Yes, it is backward compatible with USB 3.2 Gen 1 (5Gbps) and USB 2.0 (480Mbps) devices.
Q: Will this card fit in a small form factor PC?
A: Yes, it includes both full-height and low-profile brackets for versatile installation.
Our Verdict
This StarTech.com card is an excellent upgrade for any desktop PC. It adds essential high-speed USB-A connectivity. It is ideal for professionals and enthusiasts alike.
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Output interface | USB 3.2 Gen 2 (3.1 Gen 2) |
| Internal SATA ports quantity | 1 |
| Host interface | PCIe |
| Expansion card form factor | Full-height / Low-profile |
| Expansion card standard | PCIe 3.0 |
| SATA power connector type | SATA 15-pin |
| Technical details | |
| Data transfer rate (max) | 10 Gbit/s |
| Performance | |
| Data transfer rate (max) | 10 Gbit/s |
| Product colour | Black |
| Harmonized System (HS) code | 84733020 |
| Colour | |
| Product colour | Black |
| Design | |
| Internal | Yes |
| Product colour | Black |
| Features | |
| Data transfer rate (max) | 10 Gbit/s |
| Harmonized System (HS) code | 84733020 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Weight & dimensions | |
| Width | 120 mm |
| Depth | 110 mm |
| Height | 19 mm |
| Weight | 78 g |
| Package width | 216 mm |
| Package depth | 146 mm |
| Package height | 35 mm |
| Package weight | 142 g |
| Packaging data | |
| Mounting brackets included | Yes |
| Package width | 216 mm |
| Package depth | 146 mm |
| Package height | 35 mm |
| Package weight | 142 g |
| Quick installation guide | Yes |
| Logistics data | |
| Products per master (outer) case | 40 pc(s) |
| Master (outer) case width | 452 mm |
| Master (outer) case length | 377 mm |
| Master (outer) case height | 317 mm |
| Harmonized System (HS) code | 84733020 |
| Packaging content | |
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
