Ubiquiti Dream Machine Pro Max Gateway
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- 10 Gbps performance for large-scale UniFi sites
- Rack-mount design with 1U capacity and aluminium/SGCC enclosure
- Cortex-A57 ARM processor with 2000 MHz frequency and 8000 MB internal memory
- 128 GB SSD storage with LCM display and control unit
- 9 Ethernet RJ-45 ports and 2 SFP+ ports with VLAN and QoS support
- Multi-WAN load balancing with OSPF and BGP routing protocols
- Firewall security with 15 kV ESD and EMP protection
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
You may also like
Ubiquiti Dream Machine Pro Max | 10 Gbps Rackmount Gateway
The Ubiquiti Dream Machine Pro Max gateway/controller delivers 10 Gbps performance in a professional-grade, rack-mount design for large-scale UniFi deployments. This high-capacity network controller supports multi-WAN load balancing and includes two NVR drive bays, making it ideal for enterprises needing centralised security and traffic management.
Key Specs
| Metric | Spec. |
|---|---|
| Processor | ARM Cortex-A57 @ 2 GHz |
| RAM | 8 GB |
| Storage | 128 GB SSD |
| Ethernet Ports | 9x GbE + 2x SFP+ |
| Max Throughput | 10 Gbps |
Built for Enterprise-Scale Performance
The Cortex-A57 processor running at 2 GHz handles demanding routing and firewall tasks without bottlenecks. With 8 GB RAM and 128 GB SSD storage, the system processes high-volume traffic while maintaining responsive management interfaces. The 10 Gbps throughput ensures backbone connections won’t limit network expansion.
Professional-Grade Security & Control
Advanced routing protocols including OSPF and BGP provide enterprise-level network control. The integrated firewall with VLAN support creates isolated network segments for different departments or IoT devices. Quality of Service (QoS) prioritisation ensures critical applications receive bandwidth before general traffic.
Flexible Multi-WAN Connectivity
Nine Gigabit Ethernet ports plus two SFP+ uplink ports support multiple internet connections for load balancing and failover. Port aggregation combines links for increased throughput where needed. The absence of PoE means separate switches are required for powered devices, keeping the gateway focused on core routing functions.
Rack-Mount Design for Data Centres
The 1U aluminium enclosure fits standard 19″ racks while dissipating 205 BTU/h through efficient cooling. At 4.7 kg and compact 43.7 mm height, it installs easily alongside other rack equipment. LED indicators for Activity, Error, Link, and Ready provide instant status visibility without connecting to the management interface.
Box contents
- Ubiquiti Dream Machine Pro Max unit
- AC power cable
- Rack mounting hardware
- Quick start guide
Check before you buy
- Confirm your rack space can accommodate 1U height
- Verify your network requires 10 Gbps throughput capacity
- Check compatibility with your existing UniFi Controller setup
- Confirm you need SFP+ uplink capability for fibre connections
Frequently Asked Questions
Q: What mounting options are available?
A: This model is designed specifically for rack mounting in standard 19″ equipment racks.
Q: Does it support Power over Ethernet?
A: No, this gateway does not include PoE functionality. You’ll need separate PoE switches for powered devices.
Q: What routing protocols are supported?
A: The device supports OSPF and BGP for enterprise-level routing and network management.
Q: How many WAN connections can it handle?
A: With 9x GbE and 2x SFP+ ports, you can configure multiple WAN connections for load balancing and failover.
The Consultant’s verdict & warranty
The Ubiquiti Dream Machine Pro Max suits medium to large enterprises needing centralised network control with 10 Gbps performance. Its combination of enterprise routing protocols, firewall capabilities, and UniFi integration makes it suitable for organisations already invested in the UniFi ecosystem. Covered by the standard Manufacturer Warranty.
| Weight | 5.2 kg |
|---|---|
| Processor model | Cortex-A57 |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| SSD capacity | 128 GB |
| Mounting type | Rack mounting |
| Rack capacity | 1U |
| Product colour | Grey |
| Enclosure material | Aluminium/SGCC |
| DHCP server | Yes |
| Routing protocols | OSPF, BGP |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Port aggregation | Yes |
| VLAN support | Yes |
| Firewall security | Yes |
| WAN connection | Ethernet (RJ-45), SFP+ |
| Ethernet LAN RJ-45 ports | 9 |
| SFP+ ports quantity | 2 |
| Reset button | Yes |
| Quality of Service QoS support | Yes |
| Multicast support | Yes |
| Power over Ethernet PoE | No |
| Input voltage | 100 – 240 V |
| Input frequency | 50/60 Hz |
| Input current | 2 A |
| Heat dissipation | 205 BTU/h |
| DC input voltage | 12 V |
| Power consumption max | 60 W |
| Electrostatic Discharge ESD protection air | 15 kV |
| Electrostatic Discharge ESD protection contact | 8 kV |
| Electromagnetic EMP protection | Yes |
| Electromagnetic EMP protection air | 15 kV |
| Electromagnetic EMP protection contact | 8 kV |
| Weight | 4.7 kg |
| Width | 442.4 mm |
| Height | 43.7 mm |
| Depth | 285.6 mm |
| Cables included | AC |
| Operating temperature T-T | -10 – 40 °C |
| Operating relative humidity H-H | 5 – 95% |
| LED indicators | Activity, Error, Link, Ready |
| Internal memory | 8000 MB |
| Flash memory | 32000 MB |
| Display type | LCM |
| Control display unit | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Built-in processor | Yes |
| Processor frequency | 2000 MHz |
| Number of processors installed | 1 |
