GIGABYTE X870E AORUS ELITE WIFI7 Motherboard
£290.14 inc VAT
In stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- Supports AMD Ryzen 9000 CPUs
- 16+2+2 phases digital VRM for enhanced power delivery
- Supports up to 8000MHz DDR5 memory (overclocked)
- Three PCIe 5.0 slots plus one PCIe 4.0 slot for graphics and storage
- Wi-Fi 7 and 2.5GbE LAN for fast networking
Payment Methods:
You may also like
GIGABYTE A620M S2H Motherboard – AMD Ryzen 8000, DDR5, PCIe 4.0 M.2, GbE LAN
In stock
GIGABYTE B650M D3HP Motherboard – Ryzen 9000, DDR5, PCIe 4.0 M.2, 2.5GbE LAN
In stock
GIGABYTE X870E AORUS ELITE WIFI7 | AMD Ryzen 9000 Ready Powerhouse
The GIGABYTE X870E AORUS ELITE WIFI7 Motherboard – Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8000Hz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4 delivers cutting-edge performance for high-end gaming and content creation. Built on the AMD X870E chipset, this ATX motherboard supports the latest AMD Ryzen 7000/8000/9000 Series processors on Socket AM5, making it future-proof for demanding workloads and next-gen gaming.
Product Specifications
| Metric | Spec |
|---|---|
| Chipset | AMD X870E |
| Memory Support | DDR5 up to 8200MHz (OC) |
| PCIe Slots | 3x PCIe 5.0 + 1x PCIe 4.0 |
| Wi-Fi | Wi-Fi 7 (802.11be) |
| LAN | 2.5GbE Realtek RTL8125 |
Unmatched Performance for AMD Ryzen 9000 CPUs
The 16+2+2 phase digital VRM design delivers clean, stable power to your AMD Ryzen 9000 processor, ensuring peak performance during intensive tasks. Combined with support for DDR5 memory up to 8000MHz (OC), this motherboard eliminates bottlenecks for gaming, 3D rendering, and multitasking.
Future-Ready Connectivity with Wi-Fi 7
Experience lightning-fast wireless speeds with Wi-Fi 7 technology, offering significantly lower latency and higher throughput than previous generations. The integrated MediaTek MT7925 controller, paired with 2.5GbE LAN, ensures your network connection never limits your system’s potential.
Extensive Storage and Expansion Options
With four M.2 slots (three PCIe 5.0, one PCIe 4.0) and four SATA III ports, you can build a storage array supporting up to eight drives. RAID 0, 1, and 10 configurations are supported, giving you flexibility for speed or redundancy. The PCIe layout accommodates multiple high-performance GPUs and expansion cards.
Comprehensive Cooling and System Monitoring
Four chassis fan headers, two CPU fan headers, and two water pump connectors give you complete control over system cooling. PC health monitoring tracks CPU, fan speeds, temperature, and voltage in real-time, helping maintain optimal performance and longevity.
Box contents
- GIGABYTE X870E AORUS ELITE WIFI7 Motherboard
- I/O shield
- M.2 thermal guards
- SATA cables
- User manual
- Driver/software disc
- Wi-Fi antennas
Key points to check
- Confirm your AMD Ryzen processor is Socket AM5 compatible
- Verify your case supports ATX motherboard dimensions (305mm x 244mm)
- Check if your power supply has the required 24-pin ATX and 8-pin EPS connectors
- Confirm DDR5 memory compatibility with your chosen modules
Common questions
Does this motherboard support Windows 11?
What is the maximum RAM capacity?
Does it have built-in Wi-Fi?
How many M.2 slots are available?
Worth knowing before you buy
The GIGABYTE X870E AORUS ELITE WIFI7 is ideal for enthusiasts and professionals seeking maximum performance with AMD’s latest processors. Its robust power delivery, extensive connectivity options, and future-ready features make it a compelling choice for high-end gaming rigs and content creation workstations. Covered by the applicable manufacturer warranty.
| Weight | 2.2 kg |
|---|---|
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Front panel connector | Yes |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 3.1 Gen 1 connectors | 2 |
| TPM connector | Yes |
| Number of SATA III connectors | 4 |
| Number of chassis fan connectors | 4 |
| Front panel audio connector | Yes |
| EPS power connector 8-pin | Yes |
| CPU fan connector | Yes |
| ATX Power connector 24-pin | Yes |
| RGB LED pin header | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Number of CPU fan connectors | 2 |
| Number of EPS power connectors 8-pin | 2 |
| Number of water pump connectors | 2 |
| Number of RGB LED pin headers | 4 |
| Warranty period | 3 year(s) |
| Processor manufacturer | AMD |
| Maximum internal memory supported by processor | 256 GB |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor socket | Socket AM5 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 4400,4800,5200,5600,6000,6200,6400,6600,6666,6800,7000,7200,7600,7800,8000,8200 MHz |
| Supported memory module capacities | 1GB, 2GB, 4GB, 8GB, 16GB, 24GB, 32GB |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed max | 8200 MHz |
| ECC сompatibility | Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 1, 10 |
| Number of storage drives supported | 8 |
| RAID support | Yes |
| Parallel processing technology support | Not supported |
| On-board graphics card | No |
| USB 3.2 Gen 1 3.1 Gen 1 Type-A ports quantity | 4 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-A ports quantity | 2 |
| DisplayPort version | 1.4 |
| USB 2.0 ports quantity | 4 |
| WiFi-AP antenna jack | 2 |
| S/PDIF out port | Yes |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN RJ-45 ports | 1 |
| USB4 Gen 2x2 ports quantity | 2 |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| LAN controller | Realtek RTL8125 |
| Bluetooth version | 5.4 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN controller model | MediaTek MT7925 |
| Motherboard chipset family | AMD |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | CPU, Fan, Temperature, Voltage |
| Audio output channels | 7.1 channels |
| Component for | PC |
| Audio chip | Realtek ALC1220 |
| Product colour | Black |
| Number of M.2 M slots | 4 |
| PCI Express x16 Gen 3.x slots | 1 |
| PCI Express x4 slots | 2 |
| PCI Express x16 Gen 4.x slots | 1 |
| PCI Express x16 Gen 5.x slots | 1 |
| 1st M.2 largest key size | 25110 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 5.0 |
| 3rd M.2 largest key size | 22110 |
| 3rd M.2 highest PCI Express generation | 5.0 |
| 4th M.2 largest key size | 22110 |
| 4th M.2 highest PCI Express generation | 4.0 |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| Clear CMOS button | Yes |
| System Management BIOS SMBIOS version | 2.7 |
| Desktop Management Interface DMI version | 2.7 |
| DirectX version | 12.0 |
| Windows operating systems supported | Windows 11 x64 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Products per shipping inner case | 1 pc(s) |
| Country of origin | China |
| Width | 305 mm |
| Depth | 244 mm |
| Batteries included | Yes |
| Screws included | Yes |
| Antenna included | Yes |
| Height | 35 mm |
| Package width | 345 mm |
| Package depth | 294 mm |
| Package height | 80 mm |
| Package weight | 2.74 kg |
| Weight | 2.4 kg |
