GIGABYTE B650 EAGLE AX AMD Ryzen Motherboard
£135.18 inc VAT
Out of stock
Out of stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- AMD B650 chipset for Ryzen 7000/8000/9000 series CPUs
- 12+2+2 phase VRM with up to 7600MHz DDR5 memory support
- 3 M.2 slots with PCIe 5.0 and 4.0 support for storage
- ATX form factor with WiFi 6E and Bluetooth 5.3 connectivity
- 7.1 channel audio with Realtek ALC897 codec
Payment Methods:
You may also like
GIGABYTE A620M S2H Motherboard – AMD Ryzen 8000, DDR5, PCIe 4.0 M.2, GbE LAN
In stock
GIGABYTE B650 EAGLE AX | AMD Ryzen 9000 Series Ready
The GIGABYTE B650 EAGLE AX motherboard delivers robust performance for AMD Ryzen 9000 Series CPUs with its 12+2+2 phases VRM, DDR5 support up to 7600MHz (OC), and comprehensive connectivity including PCIe 5.0, Wi-Fi 6E, and USB 3.2 Gen 2. Built on the AMD B650 chipset, this ATX motherboard offers exceptional value for gamers and content creators seeking reliable performance without premium pricing.
Key Specifications
| Metric | Spec |
|---|---|
| Processor Support | AMD Ryzen 7000/8000/9000 Series |
| Memory Support | DDR5, up to 7600MHz (OC) |
| PCIe Slots | 1x PCIe 5.0, 3x PCIe 3.0 |
| M.2 Slots | 3x (1x PCIe 5.0, 2x PCIe 4.0) |
| Wi-Fi | Wi-Fi 6E + Bluetooth 5.3 |
| LAN | Gigabit Ethernet |
| Form Factor | ATX |
Superior Power Delivery for Demanding CPUs
The 12+2+2 phases VRM design provides stable power delivery for AMD Ryzen 9000 Series processors, even under heavy workloads. This robust power architecture ensures consistent performance during gaming marathons, content creation, or multitasking. The enhanced cooling solution maintains optimal temperatures, preventing thermal throttling and extending component lifespan.
Next-Generation Storage Performance
With one PCIe 5.0 M.2 slot supporting up to 128GB/s bandwidth and two PCIe 4.0 M.2 slots, this motherboard delivers exceptional storage performance. Install your fastest NVMe SSD for lightning-quick boot times and application loading. The combination of M.2 and SATA III ports provides flexible storage options for both high-speed and high-capacity needs.
Comprehensive Connectivity Options
Modern connectivity meets future-proof expansion on the B650 EAGLE AX. The integrated Wi-Fi 6E provides faster wireless speeds and lower latency, while Bluetooth 5.3 ensures reliable connections for peripherals. Multiple USB ports, including USB 3.2 Gen 2 Type-A and Type-C, offer versatile connectivity for external devices. The Gigabit Ethernet LAN delivers stable wired networking for gaming and streaming.
Enhanced Audio and Visual Experience
The Realtek ALC897 audio codec provides 7.1 channel HD audio with superior sound quality for immersive gaming and entertainment. HDMI 2.1 and DisplayPort 1.4 outputs support 4K resolution at high refresh rates, perfect for modern gaming monitors and content creation workflows. The motherboard’s audio shielding reduces interference for cleaner sound output.
Package Contents
- GIGABYTE B650 EAGLE AX motherboard
- I/O shield
- SATA cables (quantity not specified)
- User manual
- Driver/software disc
- Warranty card
- Antenna set (for Wi-Fi)
- Screws and standoffs
- CMOS battery (CR2032)
- Norton Internet Security (OEM version)
- LAN bandwidth management software
Check Before You Buy
- Confirm your AMD Ryzen CPU is supported (7000/8000/9000 Series)
- Verify your case has ATX motherboard mounting points
- Check your power supply has required connectors (24-pin ATX, 8-pin EPS)
- Confirm your CPU cooler fits the AM5 socket and motherboard dimensions
Common questions
Does this motherboard support DDR4 memory?
Can I use this with an Intel processor?
What is the maximum RAM capacity?
Does it come with Wi-Fi and Bluetooth?
Is this motherboard suitable for gaming?
Buying advice
The GIGABYTE B650 EAGLE AX offers excellent value for users building systems with AMD Ryzen 9000 Series CPUs. Its combination of PCIe 5.0 support, DDR5 memory compatibility, and comprehensive connectivity makes it a versatile choice for gaming, content creation, and everyday computing. The 12+2+2 phases VRM provides reliable power delivery for demanding processors, while the Wi-Fi 6E and Bluetooth 5.3 ensure modern wireless connectivity. Covered by the applicable manufacturer warranty, this motherboard delivers dependable performance for UK users seeking quality without premium pricing.
| Weight | 1.7 kg |
|---|---|
| Bundled software | Norton Internet Security (OEM version) LAN bandwidth management software |
| USB 3.2 Gen 2 3.1 Gen 2 connectors | 1 |
| Front panel connector | Yes |
| 12V power connector | Yes |
| USB 2.0 connectors | 3 |
| USB 3.2 Gen 1 3.1 Gen 1 connectors | 1 |
| TPM connector | Yes |
| Number of SATA III connectors | 4 |
| Number of chassis fan connectors | 3 |
| Front panel audio connector | Yes |
| EPS power connector 8-pin | Yes |
| CPU fan connector | Yes |
| ATX Power connector 24-pin | Yes |
| RGB LED pin header | Yes |
| Number of CPU fan connectors | 2 |
| Number of water pump connectors | 2 |
| Number of RGB LED pin headers | 4 |
| Serial port headers | 1 |
| Warranty period | 3 year(s) |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor socket | Socket AM5 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800,4400 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed max | 7600 MHz |
| ECC сompatibility | Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 1, 10 |
| Number of storage drives supported | 7 |
| RAID support | Yes |
| Parallel processing technology support | Not supported |
| USB 3.2 Gen 1 3.1 Gen 1 Type-C ports quantity | 1 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-A ports quantity | 2 |
| DisplayPort version | 1.4 |
| USB 2.0 ports quantity | 6 |
| WiFi-AP antenna jack | 2 |
| PS/2 ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN RJ-45 ports | 1 |
| DisplayPorts quantity | 1 |
| Line-in | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| LAN controller | Realtek RTL8111H |
| Bluetooth version | 5.3 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Realtek RTL8852CE |
| Motherboard chipset family | AMD |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Audio output channels | 7.1 channels |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Product colour | Brown |
| Number of M.2 M slots | 3 |
| PCI Express x16 Gen 3.x slots | 3 |
| PCI Express x16 Gen 4.x slots | 1 |
| 1st M.2 largest key size | 25110 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 largest key size | 22110 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| System Management BIOS SMBIOS version | 2.7 |
| Desktop Management Interface DMI version | 2.7 |
| Power source type | ATX |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| Discrete graphics support | Yes |
| DirectX version | 12.0 |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Products per shipping inner case | 1 pc(s) |
| Country of origin | China |
| Width | 305 mm |
| Depth | 244 mm |
| Batteries included | Yes |
| Screws included | Yes |
| Antenna included | Yes |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 1.94 kg |
