Asrock X870 NOVA WIFI AM5 ATX
£255.62 inc VAT
In stock
In stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- AMD X870 chipset for AMD Ryzen 7000/8000/9000 series on Socket AM5
- DDR5 memory support up to 256 GB with 8400 MHz speeds
- PCIe 5.0 M.2 slot for ultrafast SSD storage
- Wi-Fi 7 and 5 Gb/s Ethernet for high-speed connectivity
- ATX form factor with 7.1 channel audio and Polychrome RGB lighting
Payment Methods:
You may also like
ASRock X870 NOVA WIFI | AMD X870 ATX Powerhouse
The Asrock X870 NOVA WIFI AMD X870 Socket AM5 ATX motherboard delivers cutting-edge performance for AMD Ryzen 7000, 8000, and 9000 Series processors. Built on the AMD X870 chipset with Socket AM5, this ATX motherboard combines DDR5 memory support, PCIe 5.0 expansion, and Wi-Fi 7 connectivity to create a future-proof foundation for high-performance PC builds.
Specification Overview
| Metric | Spec |
|---|---|
| Socket | AM5 |
| Chipset | AMD X870 |
| Memory Support | DDR5, up to 8400 MHz |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x16 |
| Storage | 1x M.2 (PCIe 5.0), SATA III |
| Network | 5Gb Ethernet, Wi-Fi 7, Bluetooth 5.4 |
Next-Generation Memory Performance
The Asrock X870 NOVA WIFI supports DDR5-SDRAM across four DIMM slots with dual-channel architecture, enabling memory speeds up to 8400 MHz. With support for both ECC and non-ECC memory types, this motherboard accommodates up to 256 GB of system RAM. The integrated XMP/EXPO support allows enthusiasts to enable pre-tested memory profiles for stable, high-performance overclocking without manual configuration.
PCIe 5.0 Storage and Graphics Expansion
Featuring a PCIe Gen5 M.2 slot, this motherboard delivers up to 128 GB/s transfer speeds for next-generation NVMe SSDs, effectively doubling the bandwidth of previous generations. The PCIe 5.0 x16 slot provides maximum bandwidth for the latest graphics cards, while the additional PCIe 4.0 x16 slot offers flexibility for multi-GPU or expansion card configurations. The EZ Release mechanism simplifies graphics card installation and removal, making hardware upgrades straightforward.
Comprehensive Connectivity Suite
This motherboard offers extensive connectivity options including USB4 Gen 2×2 ports delivering 40 Gbps transfer rates, front panel USB 3.2 Gen2x2 Type-C headers, and multiple USB 3.2 Gen 2 and Gen 1 ports. The 5 Gigabit Ethernet controller ensures high-speed wired networking, while Wi-Fi 7 (802.11be) and Bluetooth 5.4 provide cutting-edge wireless capabilities. The Realtek ALC4082 audio codec delivers 7.1 channel high-definition sound for immersive gaming and media experiences.
Advanced Thermal Management
The Asrock X870 NOVA WIFI incorporates multiple cooling solutions including an XXL aluminum alloy M.2 heatsink with toolless design, bottom M.2 heatsink for efficient SSD cooling through the PCB, and comprehensive aluminum heatsink coverage for voltage regulation modules. These thermal solutions ensure stable performance during intensive workloads and gaming sessions by maintaining optimal operating temperatures across all components.
Package contents
- ASRock X870 NOVA WIFI motherboard
- SATA cables
- Wi-Fi antenna
- I/O shield
- User manual
- Driver/software DVD
Things to check first
- Confirm your AMD Ryzen processor is compatible with Socket AM5
- Verify your case supports ATX motherboard dimensions (305mm x 244mm)
- Check that your power supply provides sufficient PCIe power connectors
- Ensure your CPU cooler is compatible with AM5 socket mounting
Frequently Asked Questions
Does this motherboard support DDR4 memory?
What is the maximum supported memory speed?
How many M.2 SSDs can be installed?
Is Wi-Fi 7 backwards compatible with older Wi-Fi standards?
What RAID configurations are supported?
Is it worth it?
The Asrock X870 NOVA WIFI represents a premium foundation for AMD Ryzen enthusiasts seeking cutting-edge performance with comprehensive connectivity options. Its combination of DDR5 memory support, PCIe 5.0 expansion, and Wi-Fi 7 connectivity makes it ideal for gaming, content creation, and workstation applications. Covered by the applicable manufacturer warranty.
| Weight | 2.8 kg |
|---|---|
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 3.1 Gen 1 connectors | 2 |
| Front panel audio connector | Yes |
| EPS power connector 8-pin | Yes |
| CPU fan connector | Yes |
| ATX Power connector 24-pin | Yes |
| RGB LED pin header | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Number of CPU fan connectors | 2 |
| Number of EPS power connectors 8-pin | 2 |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor socket | Socket AM5 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 8400 MHz |
| Maximum internal memory | 256 GB |
| ECC сompatibility | ECC & Non-ECC |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 1, 10 |
| RAID support | Yes |
| USB 3.2 Gen 1 3.1 Gen 1 Type-A ports quantity | 3 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| S/PDIF out port | Yes |
| Microphone in | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN RJ-45 ports | 1 |
| USB4 Gen 2x2 ports quantity | 2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
| LAN controller | Realtek RTL8126 |
| Bluetooth version | 5.4 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Motherboard chipset family | AMD |
| Audio output channels | 7.1 channels |
| Component for | PC |
| Audio chip | Realtek ALC4082 |
| Number of M.2 M slots | 1 |
| PCI Express x16 Gen 4.x slots | 1 |
| PCI Express x16 Gen 5.x slots | 1 |
| BIOS type | UEFI AMI |
| BIOS memory size | 256 Mbit |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Width | 305 mm |
| Depth | 244 mm |
| Cables included | SATA |
| Antenna included | Yes |
