ASRock B860M Pro RS Motherboard, LGA 1851, Intel B860, Micro-ATX, DDR5

SKU: B860MPRORS

Original price was: £147.59.Current price is: £138.92.

In stock

In stock

  • Free Premium delivery on UK mainland orders

Order now, get it by Thu 19 Nov

  • DPD DPD tracked delivery
  • Klarna Buy now, pay later with Klarna at checkout
  • PayPal Pay in 3 instalments with PayPal at checkout

About this item

  • Intel B860 chipset for LGA 1851 processors
  • Four DDR5 DIMM slots, supporting up to 256GB
  • PCIe 5.0 x16 slot for graphics cards
  • PCIe 5.0 M.2 slot for high-speed SSDs
  • 2.5Gb Ethernet with Dragon RTL8125BG controller
  • Two HDMI outputs, DisplayPort 1.4 and USB-C
  • Micro-ATX form factor, measuring 244 × 244mm
Description

ASRock B860M Pro RS – DDR5 support in a compact build

The ASRock B860M Pro RS suits Intel PC builds that need a compact motherboard with room for substantial DDR5 memory. Its four memory slots support up to 256GB, giving you flexibility for demanding everyday computing and productivity work.

The essentials at a glance

Metric Specification
Processor socket Intel LGA 1851
Chipset Intel B860
Form factor Micro-ATX, 244 × 244 mm
Memory Four DDR5 DIMM slots, up to 256GB
Storage connectors One M.2 slot and four SATA III connectors
Networking 2.5 Gigabit Ethernet

Add memory as your needs grow

Four DDR5 slots support dual-channel memory and up to 256GB of unbuffered RAM. The board also supports Intel XMP and AMD EXPO memory profiles, so compatible modules can use their pre-tested settings.

Connect fast storage and a graphics card

The M.2 slot supports PCIe 5.0 SSDs and has a heatsink to help manage drive temperatures. Four SATA III connectors provide options for additional storage, while RAID support covers levels 0, 1, 5 and 10.

A reinforced PCIe 5.0 x16 slot supports a graphics card. There is also a PCIe 4.0 x4 slot for another compatible expansion card.

Set up wired networking and displays

Dragon 2.5 Gigabit Ethernet provides a wired network connection for gaming, streaming and file transfers. The board has no onboard Wi-Fi, so plan for a wired connection or a separate wireless solution if needed.

For displays, it offers two HDMI ports and one DisplayPort 1.4 connection. USB connectivity includes a USB-C Gen 2×2 port, three USB 3.2 Gen 1 Type-A ports and two USB 2.0 ports.

Plan your case and power connections

The 244 × 244 mm micro-ATX size suits compatible compact PC cases. A 24-pin ATX connector and an 8-pin EPS connector provide the motherboard’s listed power connections.

Four RGB LED headers support compatible lighting devices. The board also has two CPU fan connectors and three chassis fan connectors for a practical cooling setup.

Before you order

  • Confirm your processor uses the LGA 1851 socket.
  • Check that your case accepts a 244 × 244 mm micro-ATX motherboard.
  • Confirm your memory is DDR5 and fits your planned configuration.
  • Check that your power supply has 24-pin ATX and 8-pin EPS connections.

In the box

  • SATA cable

Frequently Asked Questions

Q: How much memory can this motherboard support?

A: It supports up to 256GB of DDR5 memory across four DIMM slots.

Q: Does the board include Wi-Fi?

A: No. It provides 2.5 Gigabit Ethernet for wired networking.

Q: How many storage connectors does it have?

A: It has one M.2 slot and four SATA III connectors.

Q: Which operating system does it support?

A: Windows 11 x64 is supported.

A practical choice for compact Intel builds

We recommend the ASRock B860M Pro RS for builders who want a micro-ATX Intel platform, generous DDR5 capacity and PCIe 5.0 storage support. Its wired 2.5 Gigabit Ethernet and flexible fan and RGB headers also help support a well-connected, custom build.

Specifications
Internal I/O
Number of M.2 (M) slots1
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Supported storage drive interfacesM.2, SATA III
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
TPM connectorYes
Number of SATA III connectors4
Number of chassis fan connectors3
Front panel audio connectorYes
EPS power connector (8-pin)Yes
CPU fan connectorYes
ATX Power connector (24-pin)Yes
RGB LED pin headerYes
Number of CPU fan connectors2
Number of EPS power connectors (8-pin)1
Number of RGB LED pin headers4
Technical details
Motherboard chipset familyIntel
Motherboard chipsetIntel B860
Motherboard form factormicro ATX
Component forPC
Audio
Audio output channels7.1 channels
Performance
Windows operating systems supportedWindows 11 x64
Motherboard chipset familyIntel
Motherboard chipsetIntel B860
RAID levels0, 1, 5, 10
Audio output channels7.1 channels
Motherboard form factormicro ATX
Component forPC
Processor
Processor manufacturerIntel
Processor socketLGA 1851 (Socket V1)
Memory
Number of memory slots4
Memory slots typeDIMM
Supported memory typesDDR5-SDRAM
Memory channelsDual-channel
Maximum internal memory256 GB
Unbuffered memoryYes
Storage controllers
Supported storage drive interfacesM.2, SATA III
RAID levels0, 1, 5, 10
Number of storage drives supported7
RAID supportYes
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
DisplayPort version1.4
USB 2.0 ports quantity2
Microphone inYes
HDMI ports quantity2
Ethernet LAN (RJ-45) ports1
DisplayPorts quantity1
USB 3.2 Gen 2x2 Type-C ports quantity1
Line-inYes
Network
Ethernet LANYes
Wi-FiNo
LAN controllerDragon RTL8125BG
Ethernet interface type2.5 Gigabit Ethernet
Top Wi-Fi standardNot available
Features
Windows operating systems supportedWindows 11 x64
Motherboard chipset familyIntel
Motherboard chipsetIntel B860
Audio output channels7.1 channels
Motherboard form factormicro ATX
Component forPC
Audio chipRealtek ALC897
Expansion slots
Number of M.2 (M) slots1
PCI Express x16 (Gen 5.x) slots1
PCI Express x4 (Gen 4.x) slots1
BIOS
BIOS typeEFI AMI
BIOS memory size256 Mbit
Software
Windows operating systems supportedWindows 11 x64
Weight & dimensions
Width244 mm
Depth244 mm
Packaging content
Cables includedSATA
