GIGABYTE B860 DS3H Motherboard – LGA1700, DDR5, PCIe 5.0, 2.5 GbE
£135.42 inc VAT
Out of stock
Out of stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- Intel B860 chipset for LGA 1851 socket, supporting Intel Core Ultra CPUs
- DDR5 memory support up to 9066 MHz and 256 GB maximum capacity
- Dual M.2 slots, with one PCIe 5.0 and one PCIe 4.0 interface
- 2.5 Gigabit Ethernet LAN for high-speed network connectivity
- 7.1 channel audio output and 4K resolution support via HDMI 2.1 and DisplayPort 2.1
- ATX form factor with passive cooling and comprehensive PC health monitoring
- 3-year warranty and compatible with Windows 10 x64 and Windows 11 x64
Payment Methods:
You may also like
GIGABYTE B860 – The Foundation for Next-Gen Computing
We are pleased to present the GIGABYTE B860 DS3H Motherboard – Supports Intel Core Ultra CPUs, 8+1+2+2 phases VRM, up to 9066MHz DDR5, 1xPCIe 5.0 + 1xPCIe 4.0 M.2, 2.5 GbE LAN, USB 3.2 Gen 2×2. This motherboard is ideal for PC builders and enthusiasts seeking a reliable platform for the latest Intel Core Ultra processors. It ensures robust performance and future-proof connectivity for demanding applications.
Essential System Metrics
| Metric | Spec. |
|---|---|
| Processor Socket | LGA 1851 |
| Memory Type | DDR5-SDRAM |
| Max Memory Speed | 9066 MHz |
| M.2 Slots | 2 |
| Ethernet | 2.5 Gigabit LAN |
| Form Factor | ATX |
Power Delivery for Peak Performance
This board features an 8+1+2+2 phase VRM design. This robust power delivery system ensures stable and efficient power to your Intel Core Ultra CPU. You can expect consistent performance even under heavy loads. This design also supports reliable overclocking of compatible processors.
Next-Generation Storage and Connectivity
The GIGABYTE B860 DS3H includes both a PCIe 5.0 M.2 slot and a PCIe 4.0 M.2 slot. This combination allows for incredibly fast storage solutions. You can experience rapid boot times and quick application loading. We also find 2.5 Gigabit Ethernet for superior network speeds.
Accelerated Memory Support
With support for DDR5 memory up to 9066MHz, this motherboard greatly enhances system responsiveness. High-speed DDR5 RAM is crucial for gaming, content creation, and intensive multitasking. It handles large datasets and complex operations with ease.
Comprehensive Cooling Management
Integrated PC health monitoring tools track fan speeds, temperatures, and voltages. This helps maintain optimal system stability. The board also includes multiple connectors for chassis fans and water pumps. This provides flexible cooling options for your build.
Included Components
- Screws
- Batteries
Before You Order
- Confirm your chosen CPU uses the LGA 1851 socket.
- Ensure your RAM is DDR5 compatible.
- Verify your PC case supports the ATX motherboard form factor.
- Check your power supply has an 8-pin EPS connector.
Frequently Asked Questions
Q: Does this motherboard support older Intel CPUs?
A: No, it is designed specifically for Intel Core Ultra (Series 1 and 2) processors with LGA 1851.
Q: What operating systems are supported?
A: It officially supports Windows 10 x64 and Windows 11 x64.
Q: Can I use both M.2 slots at full speed?
A: Yes, one supports PCIe 5.0 and the other PCIe 4.0, offering excellent performance.
Q: Is Wi-Fi included with this motherboard?
A: No, this model does not include integrated Wi-Fi.
Q: What audio features does it have?
A: It provides 7.1 channel audio output via a Realtek ALC897 audio chip.
Our Recommendation
The GIGABYTE B860 DS3H Motherboard is an excellent choice for anyone building a high-performance system around Intel’s Core Ultra CPUs. Its advanced power delivery, fast storage options, and high-speed DDR5 support make it a solid foundation. Warranty cover varies by product, so please contact us to confirm.
| Internal I/O | |
|---|---|
| Number of M.2 (M) slots | 2 |
| Front panel connector | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| TPM connector | Yes |
| Serial port headers | 1 |
| S/PDIF out connector | Yes |
| Number of SATA III connectors | 4 |
| Number of chassis fan connectors | 4 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| RGB LED pin header | Yes |
| Number of CPU fan connectors | 2 |
| Number of EPS power connectors (8-pin) | 1 |
| Number of water pump connectors | 3 |
| Number of RGB LED pin headers | 4 |
| Technical details | |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B860 |
| Supported processor sockets | LGA 1851 |
| Serial port headers | 1 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Parallel processing technology support | Not supported |
| HDMI version | 2.1 |
| Cooling type | Passive |
| Motherboard form factor | ATX |
| Component for | PC |
| Warranty period | 3 year(s) |
| Audio | |
| Audio output channels | 7.1 channels |
| Performance | |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B860 |
| RAID levels | 0, 1, 5, 10 |
| Supported processor sockets | LGA 1851 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Cooling type | Passive |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Processor | |
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Core™ Ultra (Series 1), Intel Core Ultra (Series 2) |
| Supported processor sockets | LGA 1851 |
| Processor socket | LGA 1851 (Socket V1) |
| Memory | |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 5600,6400,9066 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed (max) | 9066 MHz |
| ECC сompatibility | ECC & Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Storage controllers | |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 0, 1, 5, 10 |
| Number of storage drives supported | 6 |
| RAID support | Yes |
| Graphics | |
| Parallel processing technology support | Not supported |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Rear panel I/O ports | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| DisplayPort version | 2.1 |
| USB 2.0 ports quantity | 4 |
| PS/2 ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Line-in | Yes |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Realtek RTL8125 |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Features | |
| Power source type | ATX |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B860 |
| Supported processor sockets | LGA 1851 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Cooling type | Passive |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Product colour | Dark brown |
| Expansion slots | |
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 4 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| 1st M.2 largest key size | 25110 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 25110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| BIOS | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Desktop Management Interface (DMI) version | 2.7 |
| Power | |
| Power source type | ATX |
| Video | |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Packaging data | |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Software | |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Battery | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
| Country of origin | China |
| Weight & dimensions | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Weight | 2 kg |
| Width | 305 mm |
| Depth | 244 mm |
| Packaging content | |
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Batteries included | Yes |
| Screws included | Yes |
| Other features | |
| Height | 35 mm |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Weight | 2 kg |
| Identifiers | |
| Distributor SKUs | MBGIG-B860DS, 544542, STD10219247, 2120884 |
Reviews
Clear filtersThere are no reviews yet.
