GIGABYTE H810M S2H DDR5 Motherboard
£83.28 inc VAT
In stock
In stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- Intel Core Ultra (Series 2) CPU support
- 4+1+2 phase VRM design
- DDR5 memory up to 6400MHz
- 1x PCIe 4.0 M.2 slot
- 1GbE LAN with Realtek RTL8111H
- Micro ATX form factor
Payment Methods:
You may also like
ASUS PRO Q870M-C-CSM micro ATX motherboard
In stock
GIGABYTE H810M S2H | Intel Core Ultra Ready Micro ATX
The GIGABYTE H810M S2H Motherboard is engineered for Intel Core Ultra (Series 2) processors, delivering robust performance in a compact micro ATX form factor. With support for up to 6400MHz DDR5 memory, PCIe 4.0 M.2 storage, and a 4+1+2 phase VRM design, this board offers reliable power delivery for both everyday computing and demanding applications.
Specifications
| Metric | Spec |
|---|---|
| Socket | LGA 1851 |
| Memory Support | DDR5 up to 6400MHz |
| M.2 Slots | 1x PCIe 4.0 |
| Form Factor | micro ATX |
| LAN | 1GbE Realtek RTL8111H |
Built for Intel Core Ultra (Series 2) Performance
This motherboard pairs seamlessly with Intel’s latest Core Ultra processors, thanks to its LGA 1851 socket and optimised VRM configuration. The 4+1+2 phase power delivery ensures stable performance even under heavy workloads, making it ideal for content creation, office productivity, or light gaming setups.
Dual-Channel DDR5 Memory Architecture
With two DIMM slots supporting up to 128GB of DDR5 memory at speeds reaching 6400MHz, you’ll experience faster data access and improved multitasking. The dual-channel configuration maximises bandwidth, providing a noticeable performance boost for memory-intensive applications.
PCIe 4.0 M.2 Storage Ready
The single M.2 slot supports PCIe 4.0 NVMe SSDs, offering blazing-fast storage speeds for quick boot times and rapid file transfers. This is perfect for users who need responsive storage for large projects or extensive media libraries.
Comprehensive Connectivity Options
Despite its micro ATX footprint, the H810M S2H doesn’t compromise on connectivity. You’ll find USB 3.2 Gen 1 ports, HDMI 2.1 output, VGA, and PS/2 ports for legacy devices. The Realtek Gigabit LAN ensures reliable wired internet connections for streaming and online work.
Smart System Monitoring
Built-in PC health monitoring tracks fan speeds, temperatures, voltages, and water cooling systems, helping you maintain optimal system performance. The UEFI AMI BIOS provides an intuitive interface for system configuration and tuning.
What is in the box
- GIGABYTE H810M S2H Motherboard
- I/O shield
- User manual
- Driver/software disc
- SATA cables (quantity not specified)
- Screws (included)
Check before you buy
- Confirm your Intel Core Ultra (Series 2) processor is compatible with LGA 1851
- Verify your case supports micro ATX motherboards (244mm x 215mm)
- Check if your power supply has the required 24-pin ATX and 8-pin EPS connectors
- Ensure your DDR5 memory modules are compatible with 6400MHz speeds
Questions and answers
Does this motherboard support Wi-Fi?
Can I use this with non-ECC DDR5 memory?
How many storage drives can I install?
What graphics outputs are available?
Is this motherboard suitable for gaming?
Summary & warranty
The GIGABYTE H810M S2H offers excellent value for users building systems around Intel Core Ultra (Series 2) processors. Its micro ATX size makes it perfect for compact builds without sacrificing essential features like PCIe 4.0 storage and DDR5 memory support. The comprehensive connectivity options and system monitoring tools provide everything needed for a reliable, efficient PC build. Covered by the applicable manufacturer warranty.
| Weight | 0.7 kg |
|---|---|
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Front panel connector | Yes |
| USB 2.0 connectors | 1 |
| USB 3.2 Gen 1 3.1 Gen 1 connectors | 2 |
| TPM connector | Yes |
| S/PDIF out connector | Yes |
| Number of SATA III connectors | 4 |
| Number of chassis fan connectors | 2 |
| Front panel audio connector | Yes |
| EPS power connector 8-pin | Yes |
| CPU fan connector | Yes |
| ATX Power connector 24-pin | Yes |
| RGB LED pin header | Yes |
| Number of CPU fan connectors | 1 |
| Number of EPS power connectors 8-pin | 1 |
| Number of RGB LED pin headers | 2 |
| Serial port headers | 1 |
| Warranty period | 3 year(s) |
| Processor manufacturer | Intel |
| Compatible processor series | Intel Core Ultra (Series 2) |
| Processor socket | LGA 1851 (Socket V1) |
| Number of memory slots | 2 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 5600,6400 MHz |
| Maximum internal memory | 128 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed max | 6400 MHz |
| ECC сompatibility | ECC & Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
| RAID levels | 1, 5, 10 |
| Number of storage drives supported | 5 |
| RAID support | Yes |
| Parallel processing technology support | Not supported |
| USB 3.2 Gen 1 3.1 Gen 1 Type-A ports quantity | 1 |
| DisplayPort version | 2.1 |
| USB 2.0 ports quantity | 5 |
| VGA D-Sub ports quantity | 1 |
| PS/2 ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN RJ-45 ports | 1 |
| DisplayPorts quantity | 1 |
| Line-in | Yes |
| LAN controller | Realtek RTL8111H |
| Motherboard chipset family | Intel |
| Supported processor sockets | LGA 1851 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Cooling type | Passive |
| Audio output channels | 7.1 channels |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Product colour | Dark brown |
| Number of M.2 M slots | 1 |
| PCI Express x1 Gen 3.x slots | 1 |
| PCI Express x16 Gen 4.x slots | 1 |
| 1st M.2 largest key size | 2280 |
| 1st M.2 highest PCI Express generation | 4.0 |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| System Management BIOS SMBIOS version | 2.7 |
| Desktop Management Interface DMI version | 2.7 |
| Power source type | ATX |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| DirectX version | 12.0 |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Products per shipping inner case | 1 pc(s) |
| Width | 244 mm |
| Depth | 215 mm |
| Batteries included | Yes |
| Screws included | Yes |
| Height | 35 mm |
| Package width | 265 mm |
| Package depth | 265 mm |
| Package height | 54 mm |
| Package weight | 872 g |
| Weight | 790 g |
