Ubiquiti UNVR-Instant White
More Ways to Pay
-
Buy now, pay later with Klarna
-
Pay in 3 interest-free payments with PayPal
About This Item
- 4K resolution support with integrated 6-port PoE switch
- Quad-core 1.7 GHz processor with built-in HDMI display
- Single 3.5″ HDD bay with 40W total PoE budget
- Compact white design with dimensions 220 x 220 x 47 mm
- CE, FCC, IC, NDAA, and UL compliance certifications
1-3 Days
Delivery on orders over £100
£5.80
Free
Payment Methods:
You may also like
Ubiquiti UNVR-Instant White | Compact PoE NVR for 4K Surveillance
The Ubiquiti UNVR-Instant White is a compact UniFi Protect NVR designed for professional surveillance installations. This all-in-one network video recorder combines a 6-port PoE switch with integrated HDMI monitoring, supporting up to six 4K cameras or fifteen Full HD cameras from a single unit.
Key Specifications
| Metric | Spec |
|---|---|
| Processor | Quad-core 1.7 GHz |
| Storage | 1x 3.5″ HDD bay |
| PoE Ports | 6x (15.4W per port) |
| Display | 2.9 cm (1.14″) integrated screen |
| Power Consumption | 9W maximum |
Built-in PoE Switch for Simplified Installation
The UNVR-Instant White features an integrated 6-port PoE switch, eliminating the need for separate power injectors or adapters. Each port delivers up to 15.4W, sufficient for most IP cameras, while the total 40W budget ensures reliable operation across all connected devices. This design reduces cable clutter and installation time significantly.
Integrated HDMI Monitoring with On-Device Display
A built-in HDMI output connects directly to monitors for live camera viewing, while the 2.9 cm integrated display provides quick status information without requiring external equipment. This dual-display approach offers flexibility for both dedicated monitoring stations and compact installations where space is limited.
Quad-Core Processing for Smooth Performance
Powered by a 1.7 GHz quad-core processor, the NVR handles video recording, live streaming, and system management simultaneously without performance bottlenecks. The built-in processing ensures responsive operation even when managing multiple high-resolution camera feeds, making it suitable for small to medium surveillance deployments.
Box contents
- UniFi NVR unit
- Power cable
Check before you buy
- Confirm your camera models are compatible with UniFi Protect software
- Verify your total camera power requirements don’t exceed 40W PoE budget
- Check that your network infrastructure supports 1000BASE-T connections
- Ensure you have a 3.5″ HDD available for storage (not included)
Frequently Asked Questions
Q: Does this include a hard drive?
A: No, the 3.5″ HDD bay requires a separate hard drive to be installed.
Q: Can I connect non-PoE cameras to this NVR?
A: Yes, the 7 RJ-45 ports include 6 PoE ports and 1 standard Ethernet port for non-PoE devices.
Q: What is the maximum camera resolution supported?
A: The NVR supports up to 4K resolution per camera, with a total capacity of six 4K cameras or fifteen Full HD cameras.
Q: Is Wi-Fi connectivity available?
A: No, this model does not include Wi-Fi capabilities and requires wired Ethernet connections.
The Consultant’s verdict & warranty
The Ubiquiti UNVR-Instant White offers excellent value for users already invested in the UniFi ecosystem or those seeking a compact, integrated surveillance solution. The built-in PoE switch, HDMI output, and quad-core processing make it ideal for small offices, retail spaces, or home installations requiring professional-grade video management. Covered by the standard Manufacturer Warranty.
| Weight | 1.85 kg |
|---|---|
| Maximum resolution | 3840 x 2160 pixels |
| Wi-Fi | No |
| Number of HDDs supported | 1 |
| HDD size | 3.5″ |
| Ethernet LAN RJ-45 ports | 7 |
| Power over Ethernet PoE | Yes |
| HDMI output | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet PoE ports quantity | 6 |
| HDMI ports quantity | 1 |
| LED indicators | LAN, PoE |
| Reset button | Yes |
| Product colour | White |
| Built-in processor | Yes |
| Processor frequency | 1.7 GHz |
| Processor cores | 4 |
| Display diagonal | 2.9 cm (1.14″) |
| Built-in display | Yes |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption max | 9 W |
| Total Power over Ethernet PoE budget | 40 W |
| Power over Ethernet PoE power per port | 15.4 W |
| Operating temperature T-T | 0 – 40 °C |
| Operating relative humidity H-H | 5 – 95% |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA), UL |
| Width | 220 mm |
| Depth | 220 mm |
| Height | 47 mm |
| Weight | 1.04 kg |
| Cables included | Power |
| Harmonized System HS code | 85219000 |
