GIGABYTE B650M AORUS ELITE Motherboard – AMD Ryzen 9000, DDR5, PCIe 5.0 M.2, 2.5GbE, WiFi 6E
£154.57 inc VAT
In stock
In stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- AMD B650 chipset for Ryzen 9000 series processors
- 4 DIMM DDR5 slots, up to 8000MHz memory speed
- 2 M.2 slots with PCIe 5.0 and 4.0 support
- micro ATX form factor with 7.1 channel audio
- 2.5GbE LAN and Wi-Fi 6E connectivity
Payment Methods:
You may also like
GIGABYTE A620M S2H Motherboard – AMD Ryzen 8000, DDR5, PCIe 4.0 M.2, GbE LAN
In stock
GIGABYTE B650M AORUS ELITE AX ICE | Micro-ATX AMD B650 Motherboard
The GIGABYTE B650M AORUS ELITE AX ICE Motherboard delivers premium performance for AMD Ryzen 9000 Series CPUs with advanced DDR5 memory support, robust VRM design, and comprehensive connectivity options in a compact micro-ATX form factor.
Specification Overview
| Metric | Spec |
|---|---|
| Form Factor | Micro-ATX |
| CPU Support | AMD Ryzen 7000/8000/9000 Series |
| Memory Support | DDR5 up to 8000MHz (OC) |
| Storage | 2x M.2 (PCIe 5.0 + 4.0), 4x SATA III |
| Network | 2.5GbE LAN + WiFi 6E + Bluetooth 5.3 |
Next-Generation Performance for AMD Ryzen 9000
This motherboard features a 12+2+2 phase VRM design that delivers clean, stable power to AMD Ryzen 9000 Series processors. The robust power delivery system ensures consistent performance during intensive workloads and gaming sessions. Combined with four DDR5 memory slots supporting speeds up to 8000MHz (OC), you’ll experience exceptional responsiveness and multitasking capabilities.
Advanced Storage and Expansion Capabilities
With two M.2 slots supporting PCIe 5.0 and 4.0 respectively, this board offers cutting-edge storage performance. The PCIe 5.0 slot provides direct access to the latest high-speed NVMe SSDs, while the PCIe 4.0 slot offers excellent value for secondary storage. Four SATA III ports complete the storage options, giving you flexibility for various drive configurations.
Comprehensive Connectivity Suite
Stay connected with dual-band WiFi 6E and Bluetooth 5.3 for wireless peripherals and networking. The 2.5GbE LAN controller ensures fast, reliable wired connections for gaming and content creation. Multiple USB ports including USB 3.2 Gen 2×2 Type-C provide high-speed data transfer for external devices. HDMI 2.1 and DisplayPort 1.4 outputs support the latest display technologies.
Enhanced Cooling and System Monitoring
Four chassis fan headers and dual CPU fan headers give you complete control over system cooling. The motherboard includes two water pump headers for custom liquid cooling setups. PC health monitoring tracks fan speeds, temperatures, and voltages, helping you maintain optimal system performance and longevity.
Package contents
- GIGABYTE B650M AORUS ELITE AX ICE Motherboard
- I/O Shield
- User Manual
- Driver DVD
- SATA Cables
- M.2 Screws
- Wi-Fi Antenna
- Warranty Card
Things to check first
- Confirm your CPU is from the AMD Ryzen 7000/8000/9000 Series and uses Socket AM5
- Verify your case supports micro-ATX motherboard dimensions (244mm x 244mm)
- Check that your power supply has the required 24-pin ATX and 8-pin CPU power connectors
- Confirm your DDR5 memory is compatible with speeds up to 8000MHz (OC)
Frequently Asked Questions
Does this motherboard support DDR4 memory?
What size is this motherboard?
Can I use this with an Intel processor?
How many graphics cards can I install?
Does it come with built-in WiFi?
Our recommendation
The GIGABYTE B650M AORUS ELITE AX ICE offers exceptional value for users building AMD Ryzen 9000 systems who need robust performance in a compact micro-ATX package. With its powerful VRM design, DDR5 memory support, and comprehensive connectivity options, this motherboard delivers premium features at a competitive price point. Covered by the applicable manufacturer warranty.
| Weight | 1.75 kg |
|---|---|
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Front panel connector | Yes |
| 12V power connector | Yes |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 3.1 Gen 1 connectors | 1 |
| TPM connector | Yes |
| Number of SATA III connectors | 4 |
| Number of chassis fan connectors | 4 |
| Front panel audio connector | Yes |
| CPU fan connector | Yes |
| ATX Power connector 24-pin | Yes |
| RGB LED pin header | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Number of CPU fan connectors | 2 |
| Number of water pump connectors | 2 |
| Number of RGB LED pin headers | 5 |
| Serial port headers | 1 |
| Warranty period | 3 year(s) |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor socket | Socket AM5 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 4400,4800,5200,5600,6000,6200,6400,6600,6666,6800,7000,7200,7600,7800,8000 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Supported memory clock speed max | 8000 MHz |
| ECC сompatibility | Non-ECC |
| Maximum internal memory per slot | 64 GB |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 1, 10 |
| Number of storage drives supported | 6 |
| RAID support | Yes |
| Parallel processing technology support | Not supported |
| USB 3.2 Gen 1 3.1 Gen 1 Type-A ports quantity | 5 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-A ports quantity | 2 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-C ports quantity | 1 |
| DisplayPort version | 1.4 |
| USB 2.0 ports quantity | 4 |
| WiFi-AP antenna jack | 2 |
| S/PDIF out port | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN RJ-45 ports | 1 |
| DisplayPorts quantity | 1 |
| Digital audio optical out | 1 |
| Line-in | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| LAN controller | Realtek RTL8125 |
| Bluetooth version | 5.3 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Realtek RTL8852CE |
| Motherboard chipset family | AMD |
| Supported processor sockets | Socket AM5 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Audio output channels | 7.1 channels |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Product colour | White |
| Number of M.2 M slots | 2 |
| PCI Express x16 Gen 4.x slots | 2 |
| 1st M.2 largest key size | 25110 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 25110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| System Management BIOS SMBIOS version | 2.7 |
| Desktop Management Interface DMI version | 2.7 |
| Power source type | ATX |
| Maximum resolution | 4096 x 2304 pixels |
| HDCP | Yes |
| Discrete graphics support | Yes |
| DirectX version | 12.0 |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Products per shipping inner case | 1 pc(s) |
| Country of origin | China |
| Width | 244 mm |
| Depth | 244 mm |
| Batteries included | Yes |
| Screws included | Yes |
| Antenna included | Yes |
| Height | 35 mm |
| Package width | 270 mm |
| Package depth | 268 mm |
| Package height | 68 mm |
| Package weight | 1.89 kg |
