TP-Link AX6000 Ceiling Mount WiFi 6 AP
£167.74 inc VAT
In stock
In stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- AX6000 ceiling mount WiFi 6 access point
- Supports 2.4 GHz and 5 GHz bands
- Ethernet LAN data rates up to 2500 Mbit/s
- Maximum data transfer rate of 6000 Mbit/s
- Power over Ethernet (PoE) enabled
Payment Methods:
You may also like
TP-Link Omada EAP683 | Ceiling-Mount WiFi 6 Access Point
The TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point delivers enterprise-grade wireless coverage with dual-band speeds up to 6 Gbps, making it ideal for offices, retail spaces, and hospitality venues that need reliable, high-density connectivity.
Designed for ceiling or wall mounting, this access point supports up to 510 simultaneous users and includes Power over Ethernet (PoE) for simplified installation without extra power cables.
Specification Overview
| Metric | Spec |
|---|---|
| WiFi Standard | Wi-Fi 6 (802.11ax) |
| Max Speed | 6000 Mbps |
| Bands | Dual-band (2.4 GHz + 5 GHz) |
| Users Supported | 510 |
| Ethernet Ports | 1 x Gigabit PoE |
Enterprise-Grade Performance Where You Need It
The EAP683’s 6 Gbps combined wireless throughput ensures smooth 4K video streaming, VoIP calls, and cloud applications even in busy environments. With dual-band operation, devices connect to the optimal frequency automatically, reducing congestion and improving reliability across your network.
Seamless Roaming for Large Spaces
Fast roaming support allows mobile devices to move between access points without dropping connections, perfect for warehouses, hotels, or offices where users travel between rooms. The access point continuously scans channels to maintain optimal signal quality and automatically switches to the clearest channel.
Advanced Security & Management
Built-in security features include HTTPS, SNMPv3, SSH, MAC address filtering, and Access Control Lists (ACL) to protect your network from unauthorized access. The Omada SDN platform enables centralized cloud or on-premises management, making it simple to monitor performance, apply firmware updates, and configure multiple access points from one interface.
Smart Traffic Management
Quality of Service (QoS) and rate limiting ensure critical applications receive priority bandwidth while preventing any single user from monopolizing the connection. Airtime Fairness technology distributes airtime equally among devices, eliminating lag from slower clients that would otherwise slow down the entire network.
Package contents
- TP-Link Omada EAP683 ceiling mount access point
- Mounting kit
- Quick start guide
Things to check first
- Confirm your PoE switch or injector provides 12V DC power
- Verify ceiling or wall mounting location has adequate coverage area
- Check if your existing network infrastructure supports 802.11ax devices
- Ensure you have the Omada Controller app for management (cloud or on-premises)
Frequently Asked Questions
Does this support mesh networking?
Can I use this with my existing TP-Link router?
How many devices can connect simultaneously?
Is the antenna adjustable?
Does it support guest networks?
Summary & warranty
The TP-Link Omada EAP683 offers enterprise-level WiFi 6 performance in a ceiling-mount design, making it perfect for businesses needing reliable, high-density wireless coverage without complex wiring. Its combination of advanced security, centralized management, and seamless roaming makes it a solid choice for professional environments. Covered by the applicable manufacturer warranty.
| Syslog | Yes |
|---|---|
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Automatic channel selection | Yes |
| Frequency band | 2.4 – 6 GHz |
| Number of users | 510 user(s) |
| VLAN support | Yes |
| Rate limiting | Yes |
| Quality of Service QoS support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Maximum data transfer rate | 6000 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness ATF | Yes |
| Maximum data transfer rate 2.4 GHz | 1148 Mbit/s |
| Maximum data transfer rate 5 GHz | 4804 Mbit/s |
| BeamForming | Yes |
| Security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, SSH |
| MAC address filtering | Yes |
| Service Set Identifier SSID features | Multiple SSIDs |
| Ethernet LAN RJ-45 ports | 1 |
| DC-in jack | Yes |
| DC voltage range | 12 V |
| Placement | Ceiling, Wall |
| Product colour | White |
| Antenna type | Internal |
| Antenna gain level max | 5 dBi |
| Antenna direction type | Omni-directional |
| Reset button | Yes |
| Firmware upgradeable | Yes |
| LED indicators | Yes |
| Automatic channel scanning | Yes |
| Access Control List ACL | Yes |
| Fast roaming | Yes |
| Width | 220 mm |
| Depth | 220 mm |
| Height | 32.5 mm |
| Quick start guide | Yes |
| Mounting kit | Yes |
| Package type | Box |
| Operating relative humidity H-H | 10 – 90% |
| Operating temperature T-T | 0 – 40 °C |
| Storage temperature T-T | -40 – 70 °C |
| Storage relative humidity H-H | 5 – 90% |
| Quantity per pack | 1 pc(s) |
| Distributor SKUs | 10449750, 88890, 9910224, EAP683UR, NPTPL-EAP683UR, 3860570, CLEAP683UR, 18343953000 |
