HPE Aruba AP-755 (RW) Wi-Fi 7 Tri-Radio 4×4 5-pack Campus AP

HPE Aruba Networking AP-755 – Tri-band Wi-Fi 7 for dense enterprise deployments

We supply the HPE Aruba Networking AP-755 (RW) Tri Radio 4×4 Wi-Fi 7 Internal Antennas 5-pack Campus Access Point for organisations needing high-capacity indoor wireless. This flagship AP suits enterprises, healthcare, education, and retail sites that require resilient tri-band coverage and strong security. Its single strongest benefit is delivering up to 28.8 Gbps peak throughput with dual 10 Gbps wired ports for redundancy and link aggregation.

Core performance metrics

Tri-band Wi‑Fi 7 for dense user environments

The AP-755 uses three 4×4 MIMO radios to cover 2.4 GHz, 5 GHz, and 6 GHz bands with patented ultra tri-band filtering. In practice this reduces inter-band interference and sustains high throughput in crowded classrooms, wards, and retail floors. Because it supports 320 MHz channels in 6 GHz, your users get faster, more consistent connections during peak hours.

Dual 10 GbE uplinks for resilience

We fitted two 10 GbE RJ‑45 ports to give you redundant Ethernet and power via PoE, or the option to combine power from both ports. This design keeps the access point online if one link fails and helps future-proof your cabling. So your network stays available even during maintenance or unexpected faults.

Integrated IoT and location services

The AP includes two Bluetooth 5.4 radios and two USB 2.0 host ports for expanding IoT device support. A built-in GNSS receiver and barometric pressure sensor enable self-location and precise indoor positioning. Because the AP can act as a reference point, you can deploy asset tracking and location-based services without extra hardware.

Enterprise security and management

We support WPA2 and WPA3 Enterprise, Personal, and Enhanced Open (OWE) for strong wireless security. MACsec and a Trusted Platform Module help protect data in transit and at rest. HPE Aruba Networking Central provides AI-powered automation and unified management across on-premises, public cloud, VPC, or as-a-service deployments.

Robust indoor deployment options

The AP-755 is designed for indoor use with omni-directional internal antennas and a compact 240 mm x 240 mm x 56 mm footprint. It can be mounted on a wall or pole and includes a Kensington security slot for physical protection. Operating temperature ranges from 0 to 50 °C, with storage down to -40 °C and up to 70 °C.

What you receive

• HPE Aruba Networking AP-755 (RW) access point
• Mounting hardware for wall or pole installation
• Quick start guide
• Regulatory and compliance documentation

Before you order

• Confirm your switching infrastructure supports PoE class 6 for 36 W power delivery
• Verify your network planning allows for dual 10 GbE uplinks and link aggregation
• Check that your management platform is compatible with HPE Aruba Networking Wireless Operating System 10.7.0.0 or later
• Ensure indoor placement aligns with your coverage and capacity goals

Frequently Asked Questions

Q: Does the AP-755 support Wi‑Fi 6 and earlier clients?

A: Yes, it is Wi‑Fi CERTIFIED for a/b/g/n/ac/ax/be and works with legacy devices.

Q: Can I power this AP with standard PoE?

A: Yes, it supports PoE and is classed as a PD device; use PoE class 6 for full power.

Q: Are the antennas internal or external?

A: The AP-755 has internal omni-directional antennas for clean aesthetics and consistent coverage.

Q: What management options are available?

A: You can manage the AP on-premises, in public cloud, VPC, or as a service via HPE Aruba Networking Central.

Q: Is there a warranty included?

A: The 750 series includes a limited lifetime warranty; please contact us to confirm specific terms.

Our verdict for UK enterprises

The HPE Aruba Networking AP-755 (RW) Tri Radio 4×4 Wi-Fi 7 Internal Antennas 5-pack Campus Access Point is suited to high-density indoor sites that need tri-band performance, resilient wired uplinks, and integrated IoT and location services. It is a strong fit for healthcare, education, retail, and industrial environments. Warranty cover varies by product, so please contact us to confirm.
