MSI B850 GAMING PLUS WIFI Motherboard
£228.23 inc VAT
In stock
In stock
More Ways to Pay
-
Buy now, pay later with Klarna at checkout
-
Pay in 3 interest-free payments with PayPal at checkout
About This Item
- 3 M.2 slots supporting PCIe 5.0/4.0 for high-speed storage
- Wi-Fi 7 and 5G LAN for ultra-fast network connectivity
- 12+2+1 Duet Rail Power System with Core Boost technology
- Back-connect design for simplified cable management
- 4 DDR5 DIMM slots supporting up to 256GB memory at 8200MHz
- Enhanced cooling with extended heatsink and M.2 Shield Frozr
Payment Methods:
You may also like
GIGABYTE B650 GAMING X AX V2 Motherboard – AMD Ryzen 9000, DDR5, PCIe 5.0 M.2
In stock
MSI B850 GAMING PLUS WIFI PZ | AMD B850 Gaming Motherboard
The MSI B850 GAMING PLUS WIFI PZ motherboard delivers premium gaming performance with AMD B850 chipset, Socket AM5, and ATX form factor. Designed for AMD Ryzen 9000 series processors, this motherboard combines advanced connectivity, robust power delivery, and comprehensive cooling for demanding gaming and AI workloads.
Key Specifications
| Metric | Spec |
|---|---|
| Processor Support | AMD Ryzen 7000/8000/9000 Series |
| Memory Support | DDR5-SDRAM, 4x DIMM, up to 256GB |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x16, 2x PCIe 3.0 x16 |
| Storage | 3x M.2 (PCIe 5.0/4.0), 4x SATA III |
| Network | Wi-Fi 7, 5Gb Ethernet, Bluetooth 5.4 |
| Form Factor | ATX (243.8 x 304.8 mm) |
Next-Gen Connectivity for Modern Gaming
The B850 GAMING PLUS WIFI PZ features comprehensive connectivity options built for today’s gaming demands. With Wi-Fi 7 support offering the latest wireless standards including 802.11be, gamers benefit from ultra-fast wireless speeds and low latency. The 5Gb Ethernet port ensures rock-solid wired connections for competitive play, while Bluetooth 5.4 provides reliable peripheral connectivity.
Advanced Power Delivery for Sustained Performance
Built with a 12+2+1 Duet Rail Power System, this motherboard delivers stable power to AMD Ryzen processors under heavy loads. The digital CPU power system combines 8+8-pin power connectors with MSI’s exclusive Core Boost technology, ensuring consistent performance during extended gaming sessions. The back-connect design relocates power and data connectors to the rear, simplifying cable management and improving system airflow.
Comprehensive Cooling Solution
Effective thermal management is crucial for maintaining peak performance. The B850 GAMING PLUS WIFI PZ features an extended heatsink that enlarges the heat dissipation surface area, keeping components cool during intensive workloads. The M.2 Shield Frozr protects high-speed SSDs from thermal throttling, while the heavy-plated VRM heatsink covers upper MOS components. High-quality 7W/mK thermal pads and additional choke pads ensure stable operation when all cores are running at maximum frequency.
Storage Versatility and Expansion
Storage flexibility meets modern demands with three M.2 slots supporting both PCIe 5.0 and 4.0 devices. The first M.2 slot accommodates 2280-sized drives with PCIe 5.0 speeds, while the second and third slots support 22110-sized drives at PCIe 4.0 speeds. Four SATA III connectors provide additional storage options, and RAID 0/1/5/10 support enables advanced storage configurations for both performance and redundancy.
In the Box
- MSI B850 GAMING PLUS WIFI PZ motherboard
- I/O shield
- User manual
- Driver/software installation disc
- SATA cables (quantity not specified)
- M.2 screws and standoff
- Wi-Fi antenna (if applicable)
Key Points to Check
- Confirm your AMD Ryzen processor is compatible with Socket AM5
- Verify your case supports ATX motherboard dimensions (243.8 x 304.8 mm)
- Check if your power supply provides adequate PCIe power connectors (8+8-pin)
- Confirm DDR5 memory compatibility with your intended modules
Frequently Asked Questions
Does this motherboard support DDR4 memory?
Can I use this with an Intel processor?
How many graphics cards can I install?
Does it come with built-in Wi-Fi?
What is the maximum RAM capacity?
Our recommendation
The MSI B850 GAMING PLUS WIFI PZ motherboard represents an excellent choice for gamers and content creators seeking AMD Ryzen 9000 series performance with cutting-edge connectivity. The combination of PCIe 5.0 support, Wi-Fi 7, and robust power delivery makes it well-suited for high-end gaming rigs and demanding workloads. Covered by the applicable manufacturer warranty.
| USB 3.2 Gen 2 3.1 Gen 2 connectors | 1 |
|---|---|
| USB 2.0 connectors | 4 |
| USB 3.2 Gen 1 3.1 Gen 1 connectors | 4 |
| S/PDIF out connector | Yes |
| Number of SATA III connectors | 4 |
| CPU fan connector | Yes |
| RGB LED pin header | Yes |
| Number of CPU fan connectors | 4 |
| Number of water pump connectors | 1 |
| Number of RGB LED pin headers | 3 |
| Total number of SATA connectors | 4 |
| Processor manufacturer | AMD |
| Maximum internal memory supported by processor | 256 GB |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor socket | Socket AM5 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 4800,5600,6400,8200 MHz |
| Maximum internal memory | 256 GB |
| Supported memory clock speed max | 8200 MHz |
| ECC сompatibility | Non-ECC |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, Micro SATA III |
| RAID levels | 1, 5, 10 |
| Number of storage drives supported | 7 |
| RAID support | Yes |
| On-board graphics card | No |
| USB 3.2 Gen 1 3.1 Gen 1 Type-A ports quantity | 1 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-A ports quantity | 1 |
| USB 3.2 Gen 2 3.1 Gen 2 Type-C ports quantity | 2 |
| DisplayPort version | 1.2 |
| USB 2.0 ports quantity | 4 |
| HDMI ports quantity | 1 |
| Ethernet LAN RJ-45 ports | 1 |
| DisplayPorts quantity | 1 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Bluetooth version | 5.4 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Motherboard chipset family | AMD |
| Supported processor sockets | Socket AM5 |
| Audio output channels | 7.1 channels |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Product colour | Black |
| Number of M.2 M slots | 3 |
| PCI Express x16 Gen 3.x slots | 2 |
| PCI Express x16 Gen 4.x slots | 1 |
| PCI Express x16 Gen 5.x slots | 1 |
| 1st M.2 largest key size | 2280 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 largest key size | 22110 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 largest key size | 2280 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| BIOS type | UEFI AMI |
| ACPI version | 6.5 |
| System Management BIOS SMBIOS version | 3.7 |
| Windows operating systems supported | Windows 11 x64 |
| Width | 243.8 mm |
| Depth | 304.8 mm |
| Distributor SKUs | 127184, 4711377365284, 911-7E75-001, 612751 |
